Daewoo DD80 Crawler Tractor

Crawler Tractor
Crawler Tractor
Crawler Tractor
Crawler Tractor
Crawler Tractor
Crawler Tractor
Units

Dimensions

Dimensions

A

Length w/ Blade

13.68ft in

B

Width Over Tracks

6.49ft in

C

Height to Top of Cab

8.96ft in

D

Length of Track on Ground

6.75ft in

E

Ground Clearance

1.37ft in

F

Length w/o Blade

9.32ft in

Undercarriage

G

Track Gauge

4.99ft in

H

Standard Shoe Size

18in


Specifications

Engine

Number of Cylinders

6

Engine Make

2253

Engine Model

DB58

Net Power

89hp

Power Measured @

1800rpm

Max Torque

239lb ft

Displacement

353cu in

Torque Measured @

1600rpm

Operational

Operating Weight

17526.8lb

Fuel Capacity

70.1gal

Cooling System Fluid Capacity

3.8gal

Engine Oil Capacity

3.2gal

Hydraulic Fluid Capacity

32gal

Final Drives Fluid Capacity

1.2gal

Transmission

Transmission Type

Hydrostatic

Max Speed - Forward

7.3mph

Max Speed - Reverse

7.3mph

Undercarriage

Ground Pressure

5.3psi

Ground Contact Area

2911in2

Standard Shoe Size

18in

Number of Shoes per Side

39

Number of Track Rollers per Side

6

Number of Carrier Rollers per Side

1

Track Gauge

5ft in

Hydraulic System

Pump type

gear

Relief Valve Pressure

2770psi

Standard Blade

Width

8.9ft in

Capacity

2yd3

Cutting Depth

13.3in

Dimensions

Length w/o Blade

9.4ft in

Length w/ Blade

13.7ft in

Width Over Tracks

6.5ft in

Height to Top of Cab

9ft in

Length of Track on Ground

6.8ft in

Ground Clearance

1.4ft in
