Cukurova 885 Loader Backhoe
Units
Dimensions
Backhoe
J
Load Height - Std
12.64ft in
K
Reach From Swivel - Std
18.71ft in
L
Dig Depth - Std
15.1ft in
M
Reach At Load Height - Std
5.91ft in
Load Height - Ext
15.42ft in
Dig Depth - Ext
19.03ft in
Reach From Swivel - Ext
22.31ft in
Reach At Load Height - Ext
8.7ft in
Dimensions
A
Transport Length
18.95ft in
B
Transport Width
7.49ft in
C
Transport Height
12.58ft in
D
Wheelbase
7.14ft in
E
Ground Clearance
1.32ft in
Height To Top Of Suspended Cab
9.39ft in
Loader
G
Clearance At Max Dump Height
8.99ft in
H
Reach At Max Dump Height
2.07ft in
I
Dig Depth
4.45in
Bucket Breakout Force
11595.65lb
Bucket Width
89.77in
Bucket Capacity
1.44yd3
Lift Capacity At Full Height
7215.73lb
Specifications
Engine
Number Of Cylinders
4
Engine Make
2351
Engine Model
1104C-44T
Gross Power
100hp
Power Measured @
2200rpm
Net Max Torque
303.9lb ft
Aspiration
Turbocharged
Displacement
268.6cu in
Operational
Operating Weight 4wd
18078lb
Fuel Capacity
26.5gal
Hydraulic System Fluid Capacity
37gal
Oil System Fluid Capacity
2.3gal
Cooling System Fluid Capacity
6.7gal
Front Axle Fluid Capacity
2.1gal
Rear Axle Fluid Capacity
4.3gal
Turning Radius
18.1ft in
Tire Size Front - 2wd / 4wd
12.5 / 80-18
Rear Tires Size 2wd/4wd
16.9 - 28
Operating Voltage
12V
Alternator Supplied Amperage
75amps
Transmission
Transmission Type
ZF Powershift
Number Of Forward Gears
4
Number Of Reverse Gears
3
Max Speed - Forward
24.9mph
Max Speed Reverse
18.7mph
Hydraulic
Pump Type
Tandem gear
Pump Flow Capacity
40.7gal/min
Relief Valve Pressure
3190.9psi
