John Deere 410D Loader Backhoe
Units
Dimensions
Backhoe
K
Reach From Swivel - Std
18.43ft in
L
Dig Depth - Std
15.33ft in
Reach From Swivel - Ext
21.42ft in
Dig Depth - Ext
18.43ft in
Dimensions
A
Transport Length
23.42ft in
B
Transport Width
7.68ft in
C
Transport Height
11.42ft in
D
Wheelbase
6.89ft in
E
Ground Clearance
1.09ft in
Loader
G
Clearance At Max Dump Height
8.99ft in
H
Reach At Max Dump Height
2.43ft in
I
Dig Depth
4.22in
Bucket Capacity
1.26yd3
Bucket Width
89.38in
Specifications
Engine
Number Of Cylinders
4
Engine Make
2240
Engine Model
4045T
Gross Power
85hp
Net Power
75hp
Power Measured @
2200rpm
Torque Measured @
1300rpm
Net Max Torque
224lb ft
Aspiration
Naturally aspirated or turbocharged
Displacement
276cu in
Operational
Fuel Capacity
34gal
Max Weight
15600lb
Hydraulic System Fluid Capacity
11gal
Oil System Fluid Capacity
2.4gal
Cooling System Fluid Capacity
4.3gal
Transmission Fluid Capacity
11gal
Front Axle Fluid Capacity
1.8gal
Turning Radius
11.7ft in
Tire Size Front - 2wd / 4wd
11-162PR F3F/12-16.58PR F3
Rear Tires Size 2wd/4wd
19.5-24 10PR R4
Operating Voltage
12V
Alternator Supplied Amperage
78amps
Transmission
Transmission Type
Fully synchronized, 4-speed with collar shift with hydraulic reverser
Number Of Forward Gears
4
Number Of Reverse Gears
4
Hydraulic
Pump Type
Naturally aspirated and turbocharged with static and dynamic timing
