Clark Michigan CMP30 LPG Forklift

Clark Michigan CMP30 LPG Forklift Specs front
Clark Michigan CMP30 LPG Forklift Specs front
Clark Michigan CMP30 LPG Forklift Specs side
Clark Michigan CMP30 LPG Forklift Specs side
Clark Michigan CMP30 LPG Forklift Specs back
Clark Michigan CMP30 LPG Forklift Specs back
Units

Dimensions

Dimensions

A

Length to Fork Face

8.81 ft in

B

Overall Width

4.07 ft in

C

Overall Height - mast lowered

7.37 ft in

D

Wheelbase

5.58 ft in

E

Ground Clearance

4.73 in

F

Height to Top of Overhead Guard

7 ft in

G

Max Fork Height

10.83 ft in

MAST

H

Mast Tip Forward

8 degrees

I

Mast Tip Rear

10 degrees


Specifications

Engine

Number of Cylinders

4

Engine Make

2251

Engine Model

4G64

Power

47.5 hp

Torque

120 lb ft

Power Measured @

2250 rpm

Displacement

143 cu in

Torque Measured @

1600 rpm

Fuel Type

LPG

Operational

Operating Weight

9224 lb

Tire Type

Pneumatic

Number of Front Wheels

2

Number of Rear Wheels

2

Max Speed

13 mph

MAST

Load Capacity

6000 lb

Load Center

24 in

Number of Mast Sections

3

Mast Tip Forward

8 degrees

Mast Tip Rear

10 degrees

Max Fork Spread

40 in

Lift Speed

94 ft/min

Lower Speed

100 ft/min

Dimensions

Wheelbase

5.6 ft in

Length to Fork Face

8.9 ft in

Overall Width

4.1 ft in

Overall Height - mast lowered

7.4 ft in

Max Fork Height

10.9 ft in

Turning Radius

8.3 ft in

Height to Top of Overhead Guard

7 ft in

Ground Clearance

4.8 in

Right Angle Stack

9.7 ft in
