Clark Michigan 75C Wheel Loader

Clark Michigan 75C Wheel Loader Specs front
Clark Michigan 75C Wheel Loader Specs front
Clark Michigan 75C Wheel Loader Specs side
Clark Michigan 75C Wheel Loader Specs side
Clark Michigan 75C Wheel Loader Specs back
Clark Michigan 75C Wheel Loader Specs back
Units

Dimensions

Bucket

G

Dump Clearance at Max Raise

9.25 ft in

Dimensions

A

Length with Bucket on Ground

22.89 ft in

B

Width Over Tires

8.19 ft in

C

Height to Top of Cab

10.84 ft in

D

Wheelbase

9.38 ft in

E

Ground Clearance

1.15 ft in

F

Hinge Pin - Max Height

12.21 ft in

H

Reach at Max Lift and Dump

2.59 ft in


Specifications

Engine

Engine Make

2347

Engine Model

V-504C

Net Power

154.3 hp

Gross Power

152.9 hp

Displacement

504 cu in

Max Torque

374.7

Operational

Operating Weight

31482.1 lb

Fuel Capacity

70.1 gal

Hydraulic System Fluid Capacity

50.1 gal

Engine Oil Fluid Capacity

7.1 gal

Cooling System Fluid Capacity

13 gal

Transmission Fluid Capacity

8.1 gal

Front Axle/Diff Fluid Capacity

3.1 gal

Rear Axle/Diff Fluid Capacity

3.1 gal

Static Tipping Weight

27200.7 lb

Turning Radius

20 ft in

Operating Voltage

24 V

Alternator Supplied Amperage

65 amps

Rear Axle Oscillation

24 degrees

Tire Size

20.5-25 12PR (L-3)

Transmission

Transmission Type

Clark countershaft powershift

Number of Forward Gears

3

Number of Reverse Gears

3

Max Speed - Forward

20 mph

Max Speed - Reverse

20 mph

Hydraulic System

Pump Type

gear type

Relief Valve Setting

2500

Pump Flow Capacity

50 gal/min

Raise Time

6.7 sec

Dump Time

1 sec

Lower Time

3.5 sec

Bucket

Breakout Force

Dump Clearance at Max Raise

9.3 ft in

Bucket Width

8.7 ft in

Bucket Capacity - heaped

2.5 yd3

Bucket Capacity - struck

2.1 yd3

Dimensions

Length with Bucket on Ground

22.9 ft in

Width Over Tires

8.2 ft in

Height to Top of Cab

10.9 ft in

Ground Clearance

1.2 ft in

Wheelbase

9.4 ft in

Hinge Pin - Max Height

12.3 ft in

Reach at Max Lift and Dump

2.6 ft in
