Challenger MT645B 2WD Tractor

Challenger MT645B 2WD Tractor Specs front
Challenger MT645B 2WD Tractor Specs front
Challenger MT645B 2WD Tractor Specs side
Challenger MT645B 2WD Tractor Specs side
Challenger MT645B 2WD Tractor Specs back
Challenger MT645B 2WD Tractor Specs back
Units

Dimensions

Dimensions

A

Overall Length

17.2 in

B

Overall Width

9.85 ft in

D

Wheelbase

10.09 ft in

E

Ground Clearance

22.45 in


Specifications

Engine

Number of Cylinders

6

Engine Model

Endurance 74ETA

PTO Power

200 hp

Power Measured @

2200 rpm

Displacement

451.6

Aspiration

Turbocharged and Aftercooled

Operational

Operating Weight

18308 lb

Fuel Capacity

158.6 gal

Engine Oil Capacity

5.1 gal

Cooling System Fluid Capacity

9 gal

Hydraulic System Fluid Capacity

26.5 gal

3 Point Hitch Lift Capacity @ 24 inches

15604.4 lb

Operating Voltage

24 V

Alternator Supplied Amperage

150 amps

Transmission

Transmission Type

Tech Star CVT

Max Speed

25 mph

Hydraulic System

Relief Valve Setting

2900

Pump Flow Capacity

38.9 gal/min

Number of Remote Control Valves

4

Dimensions

Wheelbase

10.1 ft in

Overall Length

17.2 in

Overall Width

9.9 ft in

Height with ROPS

10.4 ft in

Ground Clearance

22.5 in
