Caterpillar R2900G Wheel Loader

Caterpillar R2900G Wheel Loader Specs front
Caterpillar R2900G Wheel Loader Specs front
Caterpillar R2900G Wheel Loader Specs side
Caterpillar R2900G Wheel Loader Specs side
Caterpillar R2900G Wheel Loader Specs back
Caterpillar R2900G Wheel Loader Specs back
Units

Dimensions

Bucket

G

Dump Clearance at Max Raise

9.42 ft in

Dimensions

A

Length with Bucket on Ground

37.08 ft in

B

Width Over Tires

9.83 ft in

C

Height to Top of Cab

9.5 ft in

D

Wheelbase

12.42 ft in

E

Ground Clearance

1.5 ft in

F

Hinge Pin - Max Height

14.92 ft in

H

Reach at Max Lift and Dump

5.42 ft in


Specifications

Engine

Engine Make

2236

Engine Model

C15 ACERT

Net Power

389 hp

Gross Power

430 hp

Power Measured @

1900 rpm

Displacement

927.9 cu in

Operational

Operating Weight

148611 lb

Fuel Capacity

225.6 gal

Hydraulic System Fluid Capacity

37 gal

Engine Oil Fluid Capacity

9 gal

Cooling System Fluid Capacity

19.8 gal

Transmission Fluid Capacity

16.4 gal

Front Axle/Diff Fluid Capacity

31.4 gal

Rear Axle/Diff Fluid Capacity

33.5 gal

Static Tipping Weight

88015 lb

Turning Radius

24.1 ft in

Rear Axle Oscillation

16 degrees

Tire Size

29.5 x 29 34 PLY STMS

Transmission

Number of Forward Gears

4

Number of Reverse Gears

4

Max Speed - Forward

15.7 mph

Max Speed - Reverse

16.4 mph

Hydraulic System

Raise Time

9.2 sec

Dump Time

3.4 sec

Lower Time

3.1 sec

Bucket

Breakout Force

60298 lb

Dump Clearance at Max Raise

9.5 ft in

Bucket Width

10 ft in

Bucket Capacity - heaped

9.4 yd3

Dimensions

Length with Bucket on Ground

37.1 ft in

Width Over Tires

9.9 ft in

Height to Top of Cab

9.5 ft in

Ground Clearance

1.5 ft in

Wheelbase

12.5 ft in

Hinge Pin - Max Height

15 ft in

Reach at Max Lift and Dump

5.5 ft in
