Caterpillar P5500 Forklift

Caterpillar P5500 Forklift Specs front
Caterpillar P5500 Forklift Specs front
Caterpillar P5500 Forklift Specs side
Caterpillar P5500 Forklift Specs side
Caterpillar P5500 Forklift Specs back
Caterpillar P5500 Forklift Specs back
Units

Dimensions

Dimensions

A

Length to Fork Face

8.68 ft in

B

Overall Width

4.19 ft in

C

Overall Height - mast lowered

7.12 ft in

D

Wheelbase

5.32 ft in

E

Ground Clearance

5.36 in

F

Height to Top of Overhead Guard

6.98 ft in

G

Max Fork Height

10.86 ft in

MAST

H

Mast Tip Forward

6 degrees

I

Mast Tip Rear

10 degrees


Specifications

Engine

Engine Model

K25

Power

63 hp

Torque

139 lb ft

Power Measured @

2700 rpm

Displacement

152 cu in

Torque Measured @

1600 rpm

Fuel Type

gas

Operational

Operating Weight

9100 lb

Tire Type

pneumatic

Number of Front Wheels

2

Number of Rear Wheels

2

Max Speed

11 mph

MAST

Load Capacity

6173 lb

Load Center

19.7 in

Mast Tip Forward

6 degrees

Mast Tip Rear

10 degrees

Max Fork Spread

39.4 in

Lift Speed

100 ft/min

Lower Speed

98 ft/min

Dimensions

Wheelbase

5.4 ft in

Length to Fork Face

8.7 ft in

Overall Width

4.2 ft in

Overall Height - mast lowered

7.2 ft in

Max Fork Height

10.9 ft in

Turning Radius

7.6 ft in

Height to Top of Overhead Guard

7 ft in

Ground Clearance

5.4 in
