Genie GTH2506 Telescopic Forklift

Genie GTH2506 Telescopic Forklift Specs front
Genie GTH2506 Telescopic Forklift Specs front
Genie GTH2506 Telescopic Forklift Specs side
Genie GTH2506 Telescopic Forklift Specs side
Genie GTH2506 Telescopic Forklift Specs extended
Genie GTH2506 Telescopic Forklift Specs extended
Units

Dimensions

Dimensions

A

Length to Fork Face

12.6 ft in

B

Width Over Tires

5.94 ft in

C

Overall Height

6.3 ft in

D

Wheelbase

7.62 ft in

E

Ground Clearance

1.09 ft in

Lift

F

Max Lift Height

19 ft in

G

Max Forward Reach

11 ft in


Specifications

Engine

Number of Cylinders

4

Engine Make

2349

Engine Model

D2011 L04, Tier 3

Gross Power

67.1 hp

Power Measured @

2500 rpm

Displacement

189.2 cu in

Operational

Operating Weight

9810.6 lb

Fuel Capacity

15.9 gal

Hydraulic System Fluid Capacity

17.2 gal

Tire Size

12-16.5 PR10

Transmission

Transmission Type

hydrostatic

Max Speed - forward

15 mph

Max Speed - reverse

15 mph

Hydraulic

Pump Type

variable displacement

Pump Flow Capacity

18.6 gal/min

Relief Valve Pressure

3771 psi

Lift

Max Lift Capacity

5511.6 lb

Max Lift Height

19 ft in

Max Load at Max Height

4409.3 lb

Max Forward Reach

11 ft in

Max Load at Max Reach

1984.2 lb

Dimensions

Length to Fork Face

12.6 ft in

Width Over Tires

6 ft in

Overall Height

6.3 ft in

Wheelbase

7.7 ft in

Ground Clearance

1.1 ft in

Turning Radius Outside Tires

11 ft in
