Caterpillar IT38G Integrated Tool Carrier

Caterpillar IT38G Integrated Tool Carrier Specs front
Caterpillar IT38G Integrated Tool Carrier Specs front
Caterpillar IT38G Integrated Tool Carrier Specs extended_1
Caterpillar IT38G Integrated Tool Carrier Specs extended_1
Caterpillar IT38G Integrated Tool Carrier Specs extended_2
Caterpillar IT38G Integrated Tool Carrier Specs extended_2
Caterpillar IT38G Integrated Tool Carrier Specs extended_3
Caterpillar IT38G Integrated Tool Carrier Specs extended_3
Units

Dimensions

Dimensions

A

Length w/ Bucket on Ground

25 ft in

B

Width Over Tires

8.5 ft in

C

Height to Top of Cab

10.83 ft in

D

Wheelbase

9.92 ft in

E

Ground Clearance

1.33 ft in

F

Hinge Pin Max Height

13.33 ft in

G

Dump Clearance at Max Lift

8.83 ft in

I

Fork Tine Length

4 ft in

K

Max Lift Height

11.75 ft in

L

Hook Height at Max Lift - standard

18.33 ft in

M

Hook Height at Max Lift - extended

22 ft in

N

Hook Reach at Max Lift - standard

8 ft in

O

Hook Reach at Max Lift - extended

11.75 ft in


Specifications

Engine

Engine Make

2236

Engine Model

3126B ATAAC

Gross Power

180 hp

Net Power

160 hp

Max Torque

619 lb ft

Torque Rise

62 %

Displacement

439

Operational

Operating Weight

32156 lb

Fuel Capacity

67.9 gal

Cooling System Fluid Capacity

11.4 gal

Engine Oil Capacity

7.9 gal

Transmission Fluid Capacity

7.9 gal

Front Diff Fluid Capacity

6.3 gal

Rear Diff Fluid Capacity

7.1 gal

Hydraulic System Fluid Capacity

20.1 gal

Turning Radius

20.1 ft in

Operating Voltage

24 V

Alternator Supplied Amperage

80 amps

Rear Axle Oscillation

12 degrees

Static Tipping Load - Bucket

22515 lb

Static Tipping Load - Forks

18306 lb

Static Tipping Load - Material Handler

12136 lb

Tire Size

20.5R25

Transmission

Transmission Type

Powershift

Number of Forward Gears

4

Number of Reverse Gears

3

Max Speed Forward

24.1 mph

Max Speed Reverse

14.5 mph

Hydraulic System

Pump Type

piston

Relief Valve Setting

3597

Pump Flow Capacity

43 gal/min

Raise Time

5.8 sec

Dump Time

2 sec

Lower Time

2.9 sec

Bucket

Breakout Force

28575 lb

Bucket Capacity - heaped

2.8 yd3

Bucket Capacity - struck

2.4 yd3

Dimensions

Width Over Tires

8.5 ft in

Height to Top of Cab

10.9 ft in

Wheelbase

10 ft in

Ground Clearance

1.4 ft in

Hinge Pin Max Height

13.4 ft in

Length w/ Bucket on Ground

25 ft in

Dump Clearance at Max Lift

8.9 ft in

Reach at Max Height and Dump

4.2 ft in

Fork Tine Length

4 ft in

Length with out Forks on Ground

26 ft in

Max Lift Height

11.8 ft in

Hook Height at Max Lift - Standard

18.4 ft in

Hook Height at Max Lift - Extended

22 ft in

Hook Reach at Max Lift - Standard

8 ft in

Hook Reach at Max Lift - Extended

11.8 ft in
