Caterpillar IT28G Integrated Tool Carrier

Caterpillar IT28G Integrated Tool Carrier Specs front
Caterpillar IT28G Integrated Tool Carrier Specs front
Caterpillar IT28G Integrated Tool Carrier Specs extended_1
Caterpillar IT28G Integrated Tool Carrier Specs extended_1
Caterpillar IT28G Integrated Tool Carrier Specs extended_2
Caterpillar IT28G Integrated Tool Carrier Specs extended_2
Caterpillar IT28G Integrated Tool Carrier Specs extended_3
Caterpillar IT28G Integrated Tool Carrier Specs extended_3
Units

Dimensions

Dimensions

A

Length w/ Bucket on Ground

24.01 ft in

C

Height to Top of Cab

10.73 ft in

D

Wheelbase

9.52 ft in

E

Ground Clearance

1.34 ft in

F

Hinge Pin Max Height

13.06 ft in

G

Dump Clearance at Max Lift

9.56 ft in

I

Fork Tine Length

3.94 ft in

K

Max Lift Height

12.61 ft in

L

Hook Height at Max Lift - standard

18.31 ft in

M

Hook Height at Max Lift - extended

23.58 ft in

N

Hook Reach at Max Lift - standard

5.28 ft in

O

Hook Reach at Max Lift - extended

9.16 ft in


Specifications

Engine

Engine Model

3116T

Gross Power

156 hp

Net Power

145 hp

Power Measured @

2300 rpm

Displacement

366.2

Operational

Operating Weight

27866.5 lb

Fuel Capacity

59.5 gal

Cooling System Fluid Capacity

11.1 gal

Engine Oil Capacity

4.3 gal

Transmission Fluid Capacity

9.2 gal

Front Diff Fluid Capacity

6.9 gal

Rear Diff Fluid Capacity

6.7 gal

Hydraulic System Fluid Capacity

33.1 gal

Turning Radius

16.7 ft in

Operating Voltage

24 V

Alternator Supplied Amperage

80 amps

Static Tipping Load - Bucket

19916.6 lb

Static Tipping Load - Material Handler

11805.8 lb

Tire Size

20.5R25 L3 XHA

Transmission

Number of Forward Gears

4

Number of Reverse Gears

3

Max Speed Forward

23.7 mph

Max Speed Reverse

16.2 mph

Hydraulic System

Relief Valve Setting

3002.3

Pump Flow Capacity

27.5 gal/min

Raise Time

6.1 sec

Dump Time

1.4 sec

Lower Time

2.8 sec

Bucket

Breakout Force

23440 lb

Bucket Capacity - heaped

2.7 yd3

Bucket Capacity - struck

2.3 yd3

Dimensions

Height to Top of Cab

10.8 ft in

Wheelbase

9.6 ft in

Ground Clearance

1.4 ft in

Hinge Pin Max Height

13.1 ft in

Length w/ Bucket on Ground

24.1 ft in

Dump Clearance at Max Lift

9.6 ft in

Reach at Max Height and Dump

3.4 ft in

Fork Tine Length

4 ft in

Length with out Forks on Ground

24.8 ft in

Max Lift Height

12.7 ft in

Hook Height at Max Lift - Standard

18.4 ft in

Hook Height at Max Lift - Extended

23.6 ft in

Hook Reach at Max Lift - Standard

5.3 ft in

Hook Reach at Max Lift - Extended

9.2 ft in
