Caterpillar D8N Crawler Tractor

Caterpillar D8N Crawler Tractor Specs front
Caterpillar D8N Crawler Tractor Specs front
Caterpillar D8N Crawler Tractor Specs side
Caterpillar D8N Crawler Tractor Specs side
Caterpillar D8N Crawler Tractor Specs back
Caterpillar D8N Crawler Tractor Specs back
Units

Dimensions

Dimensions

A

Length w/ Blade

20.56 ft in

B

Width Over Tracks

8.67 ft in

C

Height to Top of Cab

11.26 ft in

D

Length of Track on Ground

10.5 ft in

E

Ground Clearance

1.74 ft in

F

Length w/o Blade

16.26 ft in

Undercarriage

G

Track Gauge

6.84 ft in

H

Standard Shoe Size

22.05 in


Specifications

Engine

Number of Cylinders

6

Engine Make

2236

Engine Model

3406C

Gross Power

306 hp

Net Power

285 hp

Power Measured @

2100 rpm

Displacement

891 cu in

Aspiration

turbocharged and aftercooled

Operational

Operating Weight

82589.6 lb

Fuel Capacity

129 gal

Cooling System Fluid Capacity

19.6 gal

Engine Oil Capacity

9.8 gal

Hydraulic Fluid Capacity

18.5 gal

Powertrain Fluid Capacity

34.1 gal

Final Drives Fluid Capacity

3.7 gal

Operating Voltage

24 V

Alternator Supplied Amperage

50 amps

Transmission

Transmission Type

Planetary powershift

Number of Forward Gears

3

Number of Reverse Gears

3

Max Speed - Forward

6.8 mph

Max Speed - Reverse

8.7 mph

Undercarriage

Ground Pressure

14.6 psi

Ground Contact Area

5580.1 in2

Standard Shoe Size

22.1 in

Number of Shoes per Side

44

Number of Track Rollers per Side

8

Track Pitch

8.5 in

Track Gauge

6.9 ft in

Hydraulic System

Relief Valve Pressure

3500 psi

Pump Flow Capacity

63.5 gal/min

Standard Blade

Width

13 ft in

Height

66.6 in

Capacity

11.4 yd3

Cutting Depth

23 in

Dimensions

Length w/o Blade

16.3 ft in

Length w/ Blade

20.6 ft in

Width Over Tracks

8.7 ft in

Height to Top of Cab

11.3 ft in

Length of Track on Ground

10.5 ft in

Ground Clearance

1.8 ft in
