Caterpillar D7E LGP Hybrid Crawler Tractor
Units
Dimensions
Dimensions
A
Length W/ Blade
18.33ft in
B
Width Over Tracks
11.24ft in
C
Height To Top Of Cab
11.13ft in
D
Length Of Track On Ground
11.32ft in
E
Ground Clearance
1.55ft in
F
Length W/O Blade
15.12ft in
Undercarriage
G
Track Gauge
7.5ft in
H
Standard Shoe Size
36.03in
Number Of Shoes Per Side
44
Ground Pressure
6.3psi
Number Of Carrier Rollers Per Side
2
Ground Contact Area
9792in2
Number Of Track Rollers Per Side
8
Track Pitch
8.51in
Specifications
Years Of Manufacture
Approximate First Year Of Manufacture
2009A.D.
Engine
Engine Make
2236
Engine Model
C9.3 Acert
Gross Power
252hp
Net Power
235hp
Power Measured @
1700rpm
Displacement
567.6cu in
Operational
Operating Weight
62115lb
Fuel Capacity
108.1gal
Cooling System Fluid Capacity
23gal
Engine Oil Capacity
8gal
Hydraulic Fluid Capacity
20.1gal
Powertrain Fluid Capacity
15.9gal
Final Drives Fluid Capacity
11.1gal
Transmission
Transmission Type
Electric
Hydraulic System
Relief Valve Pressure
4000psi
Pump Flow Capacity
82.5gal/min
Standard Blade
Width
15ft in
Height
53in
Capacity
7.7yd3
Cutting Depth
28in
