Caterpillar D4H LGP Series II Crawler Tractor
Units
Dimensions
Dimensions
A
Length W/ Blade
16.18ft in
B
Width Over Tracks
9.06ft in
C
Height To Top Of Cab
9.95ft in
D
Length Of Track On Ground
8.6ft in
E
Ground Clearance
1.2ft in
Undercarriage
G
Track Gauge
6.57ft in
H
Standard Shoe Size
29.93in
Number Of Track Rollers Per Side
7
Ground Pressure
4.21psi
Ground Contact Area
6169.02in2
Specifications
Engine
Engine Make
2236
Engine Model
3204
Gross Power
95hp
Displacement
317.4cu in
Operational
Operating Weight
25882.3lb
Fuel Capacity
44.2gal
Transmission
Transmission Type
powershift
Number Of Forward Gears
3
Number Of Reverse Gears
3
Max Speed - Forward
6.4mph
Max Speed - Reverse
7.6mph
Standard Blade
Width
10.7ft in
Height
35.8in
Capacity
2.7yd3
Blade Angle (Both Directions)
25degrees
Cutting Depth
16.6in
