Caterpillar D3B LGP Crawler Tractor

Caterpillar D3B LGP Crawler Tractor Specs front
Caterpillar D3B LGP Crawler Tractor Specs front
Caterpillar D3B LGP Crawler Tractor Specs side
Caterpillar D3B LGP Crawler Tractor Specs side
Caterpillar D3B LGP Crawler Tractor Specs back
Caterpillar D3B LGP Crawler Tractor Specs back
Units

Dimensions

Dimensions

A

Length w/ Blade

13.13 ft in

B

Width Over Tracks

7.52 ft in

C

Height to Top of Cab

8.73 ft in

D

Length of Track on Ground

6.76 ft in

E

Ground Clearance

0.96 ft in

F

Length w/o Blade

9.78 ft in

Undercarriage

G

Track Gauge

5.42 ft in

H

Standard Shoe Size

25 in


Specifications

Engine

Engine Make

2236

Engine Model

3204

Gross Power

64.4 hp

Displacement

317.4 cu in

Operational

Operating Weight

16836.8 lb

Fuel Capacity

30.2 gal

Transmission

Transmission Type

powershift

Number of Forward Gears

3

Number of Reverse Gears

3

Max Speed - Forward

6.6 mph

Max Speed - Reverse

7.1 mph

Undercarriage

Ground Pressure

4.3 psi

Ground Contact Area

4045.6 in2

Standard Shoe Size

25 in

Number of Track Rollers per Side

6

Track Gauge

5.5 ft in

Standard Blade

Width

9.2 ft in

Dimensions

Length w/o Blade

9.8 ft in

Length w/ Blade

13.2 ft in

Width Over Tracks

7.6 ft in

Height to Top of Cab

8.8 ft in

Length of Track on Ground

6.8 ft in

Ground Clearance

1 ft in
