Caterpillar D350D Articulated Dump Truck

Articulated Dump Truck
Articulated Dump Truck
Articulated Dump Truck
Articulated Dump Truck
Articulated Dump Truck
Articulated Dump Truck
MODEL.UNITS

Dimensions

Dimensions

A

Overall Length

32.65ft in

B

Overall Width

9.85ft in

C

Overall Height

10.93ft in

D

Wheelbase

19.33ft in

F

Dump Height

21.4ft in

Dump

Capacity - Struck

20.93yd3

Capacity - Heaped

26.82yd3

Rated Payload

69976.94lb


Specifications

Engine

Engine Make

2236

Engine Model

3306

Gross Power

285.7hp

Displacement

640.8cu in

Operational

Fuel Capacity

118.9gal

Tire Size

26.5x25 Radials

Transmission

Number Of Forward Gears

5

Max Speed

29.9mph

Weights

Front Axle - Empty

30364.3lb

Center Axle - Empty

11929.3%

Rear Axle - Empty

11929.3lb

Front Axle - Loaded

42227.4%

Center Axle - Loaded

40474.7%

Rear Axle - Loaded

40474.7lb

Total Empty

54222.7lb

Total Loaded

124199.7lb
