Caterpillar D11T Crawler Tractor

Caterpillar D11T Crawler Tractor Specs front
Caterpillar D11T Crawler Tractor Specs front
Caterpillar D11T Crawler Tractor Specs side
Caterpillar D11T Crawler Tractor Specs side
Caterpillar D11T Crawler Tractor Specs back
Caterpillar D11T Crawler Tractor Specs back
Units

Dimensions

Dimensions

A

Length w/ Blade

34.9 ft in

B

Width Over Tracks

11.84 ft in

C

Height to Top of Cab

13.4 ft in

D

Length of Track on Ground

12.67 ft in

E

Ground Clearance

2.22 ft in

F

Length w/o Blade

19.75 ft in

Undercarriage

G

Track Gauge

9.51 ft in

H

Standard Shoe Size

27.96 in


Specifications

Engine

Number of Cylinders

12

Engine Make

2236

Engine Model

3508B

Gross Power

935 hp

Net Power

850 hp

Power Measured @

1800 rpm

Displacement

1958.9 cu in

Aspiration

Turbocharged

Operational

Operating Weight

230581.5 lb

Fuel Capacity

425.1 gal

Cooling System Fluid Capacity

63.1 gal

Engine Oil Capacity

28.1 gal

Hydraulic Fluid Capacity

64.2 gal

Powertrain Fluid Capacity

91 gal

Final Drives Fluid Capacity

8 gal

Operating Voltage

24 V

Alternator Supplied Amperage

100 amps

Transmission

Transmission Type

Power Shift

Number of Forward Gears

3

Number of Reverse Gears

3

Max Speed - Forward

7.3 mph

Max Speed - Reverse

8.7 mph

Undercarriage

Ground Pressure

20.1 psi

Ground Contact Area

9781 in2

Standard Shoe Size

28 in

Number of Shoes per Side

41

Number of Track Rollers per Side

8

Track Pitch

12.5 in

Track Gauge

9.6 ft in

Hydraulic System

Pump type

Gear driven

Relief Valve Pressure

3500 psi

Pump Flow Capacity

66 gal/min

Standard Blade

Width

18.4 ft in

Height

109 in

Capacity

35.5 yd3

Cutting Depth

30.2 in

Dimensions

Length w/o Blade

19.8 ft in

Length w/ Blade

34.9 ft in

Width Over Tracks

11.9 ft in

Height to Top of Cab

13.4 ft in

Length of Track on Ground

12.7 ft in

Ground Clearance

2.3 ft in
