Caterpillar CP323 Vibratory Compactor

Caterpillar CP323 Vibratory Compactor Specs front
Caterpillar CP323 Vibratory Compactor Specs front
Caterpillar CP323 Vibratory Compactor Specs side
Caterpillar CP323 Vibratory Compactor Specs side
Caterpillar CP323 Vibratory Compactor Specs back
Caterpillar CP323 Vibratory Compactor Specs back
Units

Dimensions

Dimensions

B

Width Over Tires

4.58 ft in

C

Height to Top of Cab

9.09 ft in

Drum

F

Drum Diameter

31.89 in


Specifications

Engine

Engine Make

2351

Engine Model

4.236

Gross Power

77 hp

Displacement

236.2 cu in

Operational

Operating Weight

9299.1 lb

Fuel Capacity

31.8 gal

Engine Oil Capacity

2 gal

Hydraulic System Fluid Capacity

31.8 gal

Max Speed

6.6 mph

Tires

9.5x24

Drum

Drum Width

48.1 in

Drum Diameter

31.9 in

Vibration Frequency 1

30 Hz

Centrifugal Force - High

12700 lb

Blade

Blade Width

5.5 ft in

Dimensions

Overall Length w/ Blade

14.7 ft in

Width Over Tires

4.6 ft in

Height to Top of Cab

9.1 ft in


Compare similar models

Manufacturer / Model

Operating Weight

Drum Width

Operating Weight

9920.9 lb

Drum Width

53.8 in

Operating Weight

10461 lb

Drum Width

50 in

Operating Weight

9810.6 lb

Drum Width

54 in
