Caterpillar CB564D Vibratory Smooth Drum Roller
Units
Dimensions
Dimensions
A
Overall Length
16.17ft in
B
Overall Width
7.92ft in
Height - With Rops/Fops
123in
Wheel Base
11.92ft in
Height - Steering Wheel
104in
Compaction Width
84in
Operating Specifications
E
Ground Clearance
1ft in
Curb Clearance
34.5in
Travel Speed - Maximum
8mph
Turning Radius - Inside Drum Edge
1860in
Turning Radius - Outside Drum Edge
239in
Specifications
Engine
Gross Power
130hp
Bore
4.2in
Stroke
5in
Net Power - Iso 9249
125hp
Engine Model
Cat 3054C
Net Power - Eec 80/1260
125 HP
Net Power - Saej1349 (Jun 95)
124hp
Drum
Drum Width
84in
Weights
Operating Weight - With Rops/Fops
27783lb
Operating Weight - At Front Drum With Rops/Fops
13980 lb
Operating Weight - At Rear Drum With Rops/Fops
13803 lb
Service Refill Capacities
Fuel Tank Capacity
58gal
Water Spray Tank Capacity
290gal
Vibratory System
Nominal Amplitude - High
0.1in
Nominal Amplitude - Low
0.1in
Centrifugal Force Per Drum - Maximum
25305lb
Frequency
3800 V/m
Centrifugal Force Per Drum - Minimum
18570lb
Vibration Selection
independent per drum
Drum Diameter
51in
Eccentric Weight Drive
hydraulic direct, auto reversing
