Caterpillar 950E Wheel Loader

Caterpillar 950E Wheel Loader Specs front
Caterpillar 950E Wheel Loader Specs front
Caterpillar 950E Wheel Loader Specs side
Caterpillar 950E Wheel Loader Specs side
Caterpillar 950E Wheel Loader Specs back
Caterpillar 950E Wheel Loader Specs back
Units

Dimensions

Bucket

G

Dump Clearance at Max Raise

9.36 ft in

Dimensions

A

Length with Bucket on Ground

24.77 ft in

B

Width Over Tires

9.03 ft in

C

Height to Top of Cab

11.55 ft in

D

Wheelbase

10.44 ft in

E

Ground Clearance

1.49 ft in

F

Hinge Pin - Max Height

12.96 ft in

H

Reach at Max Lift and Dump

3.81 ft in


Specifications

Engine

Engine Make

2236

Engine Model

3304

Gross Power

159.6 hp

Displacement

427.2 cu in

Operational

Operating Weight

34321.6 lb

Fuel Capacity

58.7 gal

Hydraulic System Fluid Capacity

40.5 gal

Static Tipping Weight

22566.6 lb

Turning Radius

22.7 ft in

Tire Size

23.5-25 12PR

Transmission

Number of Forward Gears

4

Number of Reverse Gears

4

Max Speed - Forward

22.5 mph

Max Speed - Reverse

24.8 mph

Hydraulic System

Raise Time

6.6 sec

Dump Time

2.2 sec

Lower Time

3 sec

Bucket

Breakout Force

30150 lb

Dump Clearance at Max Raise

9.4 ft in

Bucket Width

9.2 ft in

Bucket Capacity - heaped

3.8 yd3

Bucket Capacity - struck

3.3 yd3

Dimensions

Length with Bucket on Ground

24.8 ft in

Width Over Tires

9.1 ft in

Height to Top of Cab

11.6 ft in

Ground Clearance

1.5 ft in

Wheelbase

10.5 ft in

Hinge Pin - Max Height

13 ft in

Reach at Max Lift and Dump

3.9 ft in
