Caterpillar 938G Wheel Loader

Caterpillar 938G Wheel Loader Specs front
Caterpillar 938G Wheel Loader Specs front
Caterpillar 938G Wheel Loader Specs side
Caterpillar 938G Wheel Loader Specs side
Caterpillar 938G Wheel Loader Specs back
Caterpillar 938G Wheel Loader Specs back
Units

Dimensions

Bucket

G

Dump Clearance at Max Raise

8.93 ft in

Dimensions

A

Length with Bucket on Ground

24.04 ft in

B

Width Over Tires

8.54 ft in

C

Height to Top of Cab

10.86 ft in

E

Ground Clearance

1.32 ft in

H

Reach at Max Lift and Dump

3.47 ft in


Specifications

Engine

Engine Make

2236

Engine Model

3126DITA

Net Power

158 hp

Gross Power

145 hp

Displacement

439.4 cu in

Operational

Operating Weight

29059.2 lb

Fuel Capacity

67.1 gal

Hydraulic System Fluid Capacity

23.8 gal

Static Tipping Weight

23186.1 lb

Transmission

Transmission Type

Powershift

Number of Forward Gears

4

Number of Reverse Gears

3

Max Speed - Forward

22.4 mph

Max Speed - Reverse

13.7 mph

Hydraulic System

Raise Time

6 sec

Dump Time

1.4 sec

Lower Time

2.8 sec

Bucket

Breakout Force

24770 lb

Dump Clearance at Max Raise

9 ft in

Bucket Width

8.9 ft in

Bucket Capacity - heaped

3.2 yd3

Dimensions

Length with Bucket on Ground

24.1 ft in

Width Over Tires

8.6 ft in

Height to Top of Cab

10.9 ft in

Ground Clearance

1.4 ft in

Reach at Max Lift and Dump

3.5 ft in
