Caterpillar 928Gz Wheel Loader
Dimensions
Bucket
Dump Clearance At Max Raise
9.45ft in
Bucket Capacity - Heaped
2.62yd3
Bucket Capacity - Struck
2.23yd3
Breakout Force
_-
Bucket Width
8.37ft in
Dimensions
Ground Clearance
1.4ft in
Length With Bucket On Ground
23.8ft in
Width Over Tires
8.22ft in
Height To Top Of Cab
10.73ft in
Wheelbase
9.52ft in
Hinge Pin - Max Height
12.71ft in
Reach At Max Lift And Dump
9.45ft in
Carry Height
3ft in
Height - Center Of Axle
2.3ft in
Height - Top Of Exhaust Stack
10.6ft in
Height - Top Of Hood
87.6in
Height - Top Of Rops/Fops
10.8ft in
Length - Rear Axle To Bumper
6.4ft in
Bucket Pin Height - Maximum Lift
12.4ft in
Overall Height
16.4ft in
Overall Height - Bucket Raised
16.4ft in
Overall Length
23.1ft in
Rack Back Angle - Carry
47.8degrees
Rack Back Angle - Ground
44degrees
Rack Back Angle - Maximum Lift
58degrees
Reach At Maximum Lift And 45 Degrees Dump
3ft in
Wheel Base
9.6ft in
Wheel Base Length
9.6ft in
Width - Over Tires
6.4ft in
Digging Depth
3.4in
Bucket Clearance-Maximum Lift/Carry
12.4ft in
Dump Angle At Maximum Lift
45degrees
Centerline Of Front Axle To Hitch
4.91ft in
Dump Clearance At Maximum Lift - 45 Degrees
9.5ft in
Specifications
Engine
Engine Make
2236
Engine Model
3056E DIT ATAAC
Net Power
144.9hp
Gross Power
156.9hp
Power Measured @
2300rpm
Displacement
366cu in
Bore
4in
Stroke
5in
Rated Net Power
143hp
Sae J1349 (2)
155hp
Iso 9249 (1997) (2)
156hp
Eec 80/1269 (2)
156hp
Sae J1349 (1)
143hp
Iso 9249 (1997) (1)
145hp
Eec 80/1269 (1)
145hp
Maximum Net Power - 2000 Rpm
155hp
Operational
Operating Weight
27134.5lb
Fuel Capacity
59.5gal
Hydraulic System Fluid Capacity
33.1gal
Engine Oil Fluid Capacity
4.3gal
Cooling System Fluid Capacity
11.1gal
Transmission Fluid Capacity
9.2gal
Front Axle/Diff Fluid Capacity
6.9gal
Rear Axle/Diff Fluid Capacity
6.7gal
Static Tipping Weight
21735.4lb
Turning Radius
17.2ft in
Operating Voltage
24V
Alternator Supplied Amperage
80amps
Rear Axle Oscillation
11degrees
Tire Size
20.5-25 R25
Transmission
Transmission Type
countershaft
Number Of Forward Gears
4
Number Of Reverse Gears
3
Max Speed - Forward
23.7mph
Max Speed - Reverse
16.2mph
Forward - 1
4.9mph
Reverse - 1
4.9mph
Steering
Steering Angle - Each Direction
40degrees
Minimum Turning Radius - Over Tires
206in
Steering Cylinder, Two, Bore
2.8in
Hydraulic Output At 2300 Engine Rpm And 6900 Kpa (1000 Psi)
27 gal/min
Maximum Working Pressure
3000 psi
Steering Articulation
40degrees
Transmission
2
7.8mph
3
16mph
4
23.4mph
Weights
Operating Weight
27140lb
Tires
Tread Width
96ft in
Size
17.5-25PR (L-2)
Weights
Optional Counterweight
654.8lb
Buckets
Bucket Capacities
2.0 m3 - 2.3 m3 2.6 yd3 - 3.0 yd3
Bucket Width
8.4ft in
Capacity - Reference Bucket
2.7yd3
Type - Reference Bucket
GP
Breakout Force - Reference Bucket
25844lb
Hydraulic System
Relief Valve Setting
3597psi
Pump Flow Capacity
40.2gal/min
Raise Time
6.1sec
Dump Time
1.2sec
Lower Time
2.8sec
Pump Type
fixed displacement vane-type implement pump
Axles
Axle Oscillation
11degrees
Operating Specifications
Static Tipping Load - Full Turn
18931.1lb
Breakout Force
25844lb
Articulation Angle
40degrees
Reach - Full Lift And 45 Degrees Dump
3ft in
Dump Clearance At Full Lift And 45 Degrees Dump Angle
9.5ft in
Service Refill Capacities
Cooling System
11.1gal
Fuel Tank
59.4gal
Crankcase
3.7gal
Hydraulic Tank
18.5gal
Hydraulic System - Including Tank
33gal
Transmission
9.1gal
Front
6.9gal
Rear
6.6gal
Cab
Rops
SAE J1040 MAY94, ISO 3471-1994
Fops
SAE J/ISO 3449 APR98 Level II, ISO 3449-1992 Level II
Loader Hydraulic System
Relief Valve Setting
3600 psi
Pump Flow - Implement Pump
40.15 gal/min
Output At 2,300 Engine Rpm And 6900 Kpa (1000 Psi) With Sae 10w Oil At 65 Degreesc (150 Degreesf)
40.3 gal/min
Raise
6.1 s
Dump
1.2 s
Lower, Empty, Float Down
2.8 s
Total
10.1 s
Bore (1)
4.8in
Stroke (1)
27in
Bore (2)
5in
Stroke (2)
21.7in
Hydraulic Cycle Time
10.1 s
