Caterpillar 924G Pin On Wheel Loader

Caterpillar 924G Pin On Wheel Loader Specs front
Caterpillar 924G Pin On Wheel Loader Specs front
Caterpillar 924G Pin On Wheel Loader Specs side
Caterpillar 924G Pin On Wheel Loader Specs side
Caterpillar 924G Pin On Wheel Loader Specs back
Caterpillar 924G Pin On Wheel Loader Specs back
Units

Dimensions

Bucket

G

Dump Clearance at Max Raise

9.36 ft in

Dimensions

A

Length with Bucket on Ground

23.1 ft in

B

Width Over Tires

7.73 ft in

E

Ground Clearance

1.21 ft in

H

Reach at Max Lift and Dump

3.15 ft in


Specifications

Engine

Engine Model

3056T

Net Power

110 hp

Displacement

366.2 cu in

Operational

Operating Weight

22571 lb

Fuel Capacity

52.4 gal

Hydraulic System Fluid Capacity

39.7 gal

Static Tipping Weight

17359.2 lb

Transmission

Number of Forward Gears

4

Number of Reverse Gears

3

Max Speed - Forward

24 mph

Max Speed - Reverse

13.5 mph

Hydraulic System

Raise Time

5.1 sec

Dump Time

1.4 sec

Lower Time

2.4 sec

Bucket

Breakout Force

25195 lb

Dump Clearance at Max Raise

9.4 ft in

Bucket Width

8.4 ft in

Bucket Capacity - heaped

2 yd3

Dimensions

Length with Bucket on Ground

23.1 ft in

Width Over Tires

7.8 ft in

Ground Clearance

1.3 ft in

Reach at Max Lift and Dump

3.2 ft in
