Caterpillar 914G Wheel Loader

Caterpillar 914G Wheel Loader Specs front
Caterpillar 914G Wheel Loader Specs front
Caterpillar 914G Wheel Loader Specs side
Caterpillar 914G Wheel Loader Specs side
Caterpillar 914G Wheel Loader Specs back
Caterpillar 914G Wheel Loader Specs back
Units

Dimensions

Bucket

G

Dump Clearance at Max Raise

8.75 ft in

Dimensions

A

Length with Bucket on Ground

20.43 ft in

B

Width Over Tires

7.92 ft in

C

Height to Top of Cab

10.17 ft in

D

Wheelbase

8.5 ft in

E

Ground Clearance

1.5 ft in

F

Hinge Pin - Max Height

11.25 ft in

H

Reach at Max Lift and Dump

3.17 ft in


Specifications

Engine

Engine Make

2236

Engine Model

3054 Turbocharged diesel

Net Power

96 hp

Gross Power

100 hp

Power Measured @

2300 rpm

Displacement

268.6 cu in

Operational

Operating Weight

16262 lb

Fuel Capacity

39.6 gal

Hydraulic System Fluid Capacity

26.4 gal

Engine Oil Fluid Capacity

1.8 gal

Cooling System Fluid Capacity

5.8 gal

Front Axle/Diff Fluid Capacity

4 gal

Rear Axle/Diff Fluid Capacity

4 gal

Static Tipping Weight

11737 lb

Turning Radius

15.6 ft in

Operating Voltage

12 V

Alternator Supplied Amperage

60 amps

Rear Axle Oscillation

22 degrees

Tire Size

17.5-R25,radial(L-2/L3 equivalent)

Transmission

Transmission Type

Hydrostatic

Number of Forward Gears

2

Number of Reverse Gears

2

Max Speed - Forward

21.7 mph

Max Speed - Reverse

21.7 mph

Hydraulic System

Pump Type

fixed displacement

Relief Valve Setting

3560

Pump Flow Capacity

23.8 gal/min

Raise Time

5.6 sec

Dump Time

2.1 sec

Lower Time

3.2 sec

Bucket

Breakout Force

14007 lb

Dump Clearance at Max Raise

8.8 ft in

Bucket Width

7.9 ft in

Bucket Capacity - heaped

1.7 yd3

Bucket Capacity - struck

1.4 yd3

Dimensions

Length with Bucket on Ground

20.5 ft in

Width Over Tires

8 ft in

Height to Top of Cab

10.2 ft in

Ground Clearance

1.5 ft in

Wheelbase

8.5 ft in

Hinge Pin - Max Height

11.3 ft in

Reach at Max Lift and Dump

3.2 ft in
