Caterpillar 815F Series II Compactor

Caterpillar 815F Series II Compactor Specs front
Caterpillar 815F Series II Compactor Specs front
Caterpillar 815F Series II Compactor Specs side
Caterpillar 815F Series II Compactor Specs side
Caterpillar 815F Series II Compactor Specs back
Caterpillar 815F Series II Compactor Specs back
Units

Dimensions

Dimensions

A

Length With Blade on Ground

22.46 ft in

B

Width Over Wheels

10.64 ft in

C

Height to Top of Cab

10.99 ft in

D

Wheelbase

11 ft in

E

Ground Clearance

1.28 ft in


Specifications

Engine

Number of Cylinders

6

Engine Make

2236

Engine Model

C9 Acert

Gross Power

253.5 hp

Net Power

232 hp

Power Measured @

2100 rpm

Displacement

537.1 cu in

Operational

Operating Weight

45757 lb

Fuel Capacity

117.9 gal

Hydraulic System Fluid Capacity

23.3 gal

Engine Oil Capacity

9 gal

Cooling System Fluid Capacity

14.6 gal

Transmission Fluid Capacity

13.3 gal

Operating Voltage

24 V

Alternator Supplied Amperage

80 amps

Transmission

Transmission Type

Planetary

Number of Forward Gears

3

Number of Reverse Gears

3

Max Speed

12.2 mph

Wheels

Front Wheels Drum Width

39.1 in

Front Wheels Drum Diameter

40.6 in

Rear Wheels Drum Width

39.1 in

Rear Wheels Drum Diameter

40.6 in

Blade

Height

33.9 in

Width

12 ft in

Dimensions

Length with Blade on Ground

22.5 ft in

Width Over Wheels

10.7 ft in

Height to Top of Cab

11 ft in

Wheelbase

11 ft in

Ground Clearance

1.3 ft in
