Caterpillar 518 Cable Skidder

Skidder
Skidder
Skidder
Skidder
Skidder
Skidder
Units

Dimensions

Dimensions

A

Overall Length

18.77 ft in

B

Overall Width

8.67 ft in

C

Height to Top of Cab

9.55 ft in

D

Wheelbase

10.67 ft in

E

Ground Clearance

1.55 ft in


Specifications

Engine

Engine Make

2236

Engine Model

3304

Gross Power

130 hp

Displacement

427.2 cu in

Operational

Operating Weight

22597.4 lb

Fuel Capacity

51 gal

Hydraulic System Fluid Capacity

7.7 gal

Axle Oscillation

14 degrees

Tire Size

23.1-26

Transmission

Number of Forward Gears

3

Number of Reverse Gears

3

Max Speed - Forward

15 mph

Max Speed - Reverse

17.9 mph

Dimensions

Overall Width

8.7 ft in

Blade Width

7.1 ft in

Height to Top of Cab

9.6 ft in

Wheelbase

10.7 ft in

Ground Clearance

1.6 ft in

Overall Length

18.8 ft in

Drum Diameter

10.1 in

Cable Width

0.7 in

Drum Capacity at Cable Width

249.4 ft in

Max Line Pull - bare drum

26363 lb

Max Line Speed

301.9 ft/min
