John Deere 540G Series II Skidder

John Deere 540G Series II Skidder Specs front
John Deere 540G Series II Skidder Specs front
John Deere 540G Series II Skidder Specs back
John Deere 540G Series II Skidder Specs back
John Deere 540G Series II Skidder Specs extended
John Deere 540G Series II Skidder Specs extended
Units

Dimensions

Dimensions

B

Overall Width

9.17 ft in

C

Height to Top of Cab

9.89 ft in

D

Wheelbase

9.58 ft in

E

Ground Clearance

1.63 ft in


Specifications

Engine

Number of Cylinders

6

Engine Make

2240

Engine Model

6068T

Gross Power

127 hp

Net Power

119 hp

Power Measured @

2200 rpm

Peak Torque

398 lb ft

Torque Measured @

1400 rpm

Displacement

414 cu in

Aspiration

turbocharged

Operational

Operating Weight

21990 lb

Fuel Capacity

42 gal

Cooling System Fluid Capacity

7.5 gal

Engine Oil Capacity

5 gal

Front Diff Fluid Capacity

4.5 gal

Rear Diff Fluid Capacity

4.5 gal

Transmission Fluid Capacity

7.8 gal

Hydraulic System Fluid Capacity

8 gal

Operational Voltage

12 V

Alternator Supplied Amperage

65 amps

Axle Oscillation

30 degrees

Steering Angle

90 degrees

Tire Size

23.1-26

Transmission

Transmission Type

planetary

Number of Forward Gears

8

Number of Reverse Gears

7

Max Speed - Forward

11.8 mph

Max Speed - Reverse

8.9 mph

Hydraulic

Pump Type

variable displacement axial piston

Pump Flow

27 gal/min

Relief Valve Pressure

3000 psi

Dimensions

Overall Width

9.2 ft in

Height to Top of Cab

9.9 ft in

Max Blade Height

47.6 in

Wheelbase

9.6 ft in

Ground Clearance

1.7 ft in

Drum Diameter

8 in

Cable Width

0.7 in

Drum Capacity at Cable Width

254 ft in

Max Line Pull - bare drum

40525 lb

Max Line Speed

146 ft/min
