Caterpillar 517 Grapple Skidder

Caterpillar 517 Grapple Skidder Specs front
Caterpillar 517 Grapple Skidder Specs front
Caterpillar 517 Grapple Skidder Specs back
Caterpillar 517 Grapple Skidder Specs back
Caterpillar 517 Grapple Skidder Specs extended
Caterpillar 517 Grapple Skidder Specs extended
Units

Dimensions

Dimensions

C

Height to Top of Cab

8.14 ft in

E

Ground Clearance

2.09 ft in

H

Reach of Grapple at Ground Level

4.08 ft in

I

Tong Opening at Tips

6.99 ft in

Undercarriage

D

Length of Track on Ground

9.55 ft in


Specifications

Engine

Engine Model

3304 DIT

Gross Power

1201 hp

Displacement

427.2 cu in

Operational

Operating Weight

40454.9 lb

Fuel Capacity

68.7 gal

Undercarriage

Width of Shoes

26 in

Number of Track Rollers per Side

8

Length of Track on Ground

9.6 ft in

Ground Contact Area

5456.1 in2

Dimensions

Blade Width

9 ft in

Height to Top of Cab

8.2 ft in

Ground Clearance

2.1 ft in

Reach of Grapple at Ground Level

4.1 ft in

Tong Opening at Tips

7 ft in

Grapple Capacity - tongs tip to tip

8 ft2

Drum Diameter

10 in

Max Line Pull - bare drum

68780 lb

Max Line Speed

132.9 ft/min
