Caterpillar 432E Loader Backhoe

Caterpillar 432E Loader Backhoe Specs front
Caterpillar 432E Loader Backhoe Specs front
Caterpillar 432E Loader Backhoe Specs side
Caterpillar 432E Loader Backhoe Specs side
Caterpillar 432E Loader Backhoe Specs extended
Caterpillar 432E Loader Backhoe Specs extended
Units

Dimensions

Backhoe

J

Load Height - Std

12.29 ft in

K

Reach From Swivel - Std

18.34 ft in

L

Dig Depth - Std

16.17 ft in

Dimensions

A

Transport Length

19.07 ft in

B

Transport Width

7.72 ft in

C

Transport Height

12.2 ft in

D

Wheelbase

7.22 ft in

Loader

G

Clearance at Max Dump Height

8.76 ft in

I

Dig Depth

3.59 in


Specifications

Engine

Number of Cylinders

4

Engine Make

2236

Engine Model

3054C

Net Power

91 hp

Gross Power

94 hp

Net Torque Rise

37 %

Displacement

268.6 cu in

Operational

Max Weight

23589.5 lb

Fuel Capacity

38.4 gal

Hydraulic System Fluid Capacity

10.1 gal

Cooling System Fluid Capacity

4.3 gal

Transmission Fluid Capacity

5.1 gal

Front Axle Fluid Capacity

3 gal

Rear Axle Fluid Capacity

4.3 gal

Turning Radius

17.8 ft in

Backhoe

Dig Depth - Std

16.2 ft in

Dig Depth - Ext

19.6 ft in

Reach From Swivel - Std

18.4 ft in

Load Height - Std

12.3 ft in

Load Height - Ext

14 ft in

Transmission

Transmission Type

Caterpillar Power-Shuttle or optional Autoshift transmission

Number of Forward Gears

5

Number of Reverse Gears

5

Max Speed - Forward

25.5 mph

Max Speed Reverse

24.9 mph

Loader

Bucket Capacity

1.4 yd3

Bucket Width

94.8 in

Lift Capacity at Full Height

8104.2 lb

Clearance at Max Dump Height

8.8 ft in

Dig Depth

3.6 in

Hydraulic

Pump Type

Variable-Flow, Axial-Piston

Pump Flow Capacity

41.3 gal/min

Relief Valve Pressure

249 psi

Dimensions

Transport Length

19.1 ft in

Transport Width

7.8 ft in

Transport Height

12.2 ft in

Height to Top of Suspended Cab

9.4 ft in

Wheelbase

7.3 ft in
