Caterpillar 385C FS Hydraulic Excavator

Caterpillar 385C FS Hydraulic Excavator Specs front
Caterpillar 385C FS Hydraulic Excavator Specs front
Caterpillar 385C FS Hydraulic Excavator Specs side
Caterpillar 385C FS Hydraulic Excavator Specs side
Caterpillar 385C FS Hydraulic Excavator Specs extended
Caterpillar 385C FS Hydraulic Excavator Specs extended
Units

Dimensions

Dimensions

B

Width to Outside of Tracks

11.16 ft in

D

Length of Track on Ground

19.17 ft in

E

Ground Clearance

2.79 ft in

G

Height to Top of Cab

14.77 ft in

H

Tail Swing Radius

15.06 ft in

Undercarriage

F

Track Gauge

11.52 ft in

N

Shoe Size

25.6 in


Specifications

Engine

Engine Make

2236

Engine Model

C18 Acert

Gross Power

553 hp

Net Power

537 hp

Power Measured @

1800 rpm

Displacement

1104.6 cu in

Operational

Operating Weight

199738.8 lb

Fuel Capacity

327.6 gal

Cooling System Fluid Capacity

26.7 gal

Hydraulic System Fluid Capacity

262.9 gal

Engine Oil Capacity

17.2 gal

Swing Drive Fluid Capacity

5.1 gal

Hydraulic System Relief Valve Pressure

4641.3 psi

Hydraulic Pump Flow Capacity

258.9 gal/min

Swing Mechanism

Swing Speed

6.4 rpm

Swing Torque

191.8 lb ft

Undercarriage

Number of Shoes per Side

47

Shoe Size

25.6 in

Number of Carrier Rollers per Side

3

Number of Track Rollers per Side

8

Max Travel Speed

2.8 mph

Drawbar Pull

133086.9 lb

Track Gauge

11.6 ft in

Buckets

Reference Bucket Capacity

3.9 yd3

Maximum Bucket Capacity

7.1 yd3

Dimensions

Width to Outside of Tracks

11.2 ft in

Height to Top of Cab

14.8 ft in

Ground Clearance

2.8 ft in

Removal Counterweight Clearance

5.4 ft in

Tail Swing Radius

15.1 ft in

Length of Track on Ground

19.2 ft in
