Caterpillar 262C Skid Steer Loader

Skid Steer Loader
Skid Steer Loader
Skid Steer Loader
Skid Steer Loader
Skid Steer Loader
Skid Steer Loader
Units

Dimensions

Dimensions

A

Length With Bucket

12.08ft in

B

Width Over Tires

5.5ft in

E

Ground Clearance

8.81in

C

Height To Top Of Cab

6.83ft in

D

Wheelbase

4.07ft in

F

Length W/O Bucket

10.25ft in

G

Clearance At Max Lift And Dump

8.03ft in

H

Reach At Max Lift And Dump

30.7in

Length - With Bucket On Ground

145in

Length - Without Bucket

117in

Maximum Dump Angle

50 degrees

Maximum Reach - With Arms Parallel

50.5in

Rack Back Angle - Maximum Height

85 degrees

Reach - Maximum Lift/Dump

30.7in

Maximum Overall Height

160.4in

Bucket Pin Height - Carry Position

7.8in

Bucket Pin Height - Maximum Lift

10.59ft in

Bucket Pin Reach - Maximum Lift

14.7in

Bumper Overhang - Rear Axle

42.8in

Clearance At Maximum Lift And Dump

96.4in

Departure Angle

26 degrees

Height - Top Of Cab

6.9ft in

Turning Radius From Center - Inc Bucket

97.8in

Turning Radius From Center - Machine Rear

56.8in

Vehicle Width Over Tires

66in

Wheel Base

4.07ft in

Turn Radius From Center - Bucket

85.3in

Turn Radius From Center - Coupler

54.6in

Turn Radius From Center - Rear

68.1in

Operating Specifications

Rated Operating Capacity With Optional Counterweight

2945lb

Tipping Load

5400lb

Breakout Force - Tilt Cylinder

7315lb

Rated Operating Capacity

2700lb


Specifications

Engine

Number Of Cylinders

4

Engine Make

2236

Engine Model

3044C DIT

Gross Power

84hp

Net Power

82hp

Power Measured @

2500rpm

Displacement

201cu in

Bore

3.7in

Stroke

4.7in

Gross Power - Sae J1995

84hp

Engine Model

Cat C3.4 DIT

Engine Power - Iso 14396

83hp

Net Power - Eec 80/1269

83hp

Net Power - Iso 9249 Eec

83hp

Net Power - Sae 1349

82hp

Net Flywheel Power

82hp

Operational

Operational Weight

7968lb

Fuel Capacity

26gal

Cooling System Fluid Capacity

3.7gal

Engine Oil Fluid Capacity

2.6gal

Hydraulic System Fluid Capacity

15gal

Max Speed

7.7mph

Chain Box Fluid Capacity - Each Side

2.6gal

Operating Voltage

12V

Alternator Supplied Amperage

90amps

Power Train

Travel Speed Forward

7.7mph

Travel Speed Reverse

7.7mph

Travel Speed Reverse - 2-Speed Option

12mph

Travel Speed Forward - 2-Speed Option

12mph

Xdp Option Speed - With Tires

6.5mph

Xdp Option Speed - With Vts Tracks

4.8mph

Loader

Breakout Force

7315lb

Operating Load Rating

2700lb

Tipping Angle

5400degrees

Bucket Capacity

0.6yd3

Weights

Operating Weight

7968lb

Hydraulic

Pump Flow Capacity

22gal/min

Relief Valve Pressure

3335psi

Hydraulic System

Hydraulic Flow (1)

Standard

Hydraulic Power

42.8hp

Maximum Loader Hydraulic Flow

33 gal/min

Maximum Loader Hydraulic Pressure

4061 psi

Loader Hydraulic Pressure

3335 psi

Loader Hydraulic Flow

22 gal/min

Hydraulic Flow (2)

High Flow XPS

Service Refill Capacities

Cooling System

3.7gal

Fuel Tank

26gal

Hydraulic Tank

11gal

Engine Crankcase

2.6gal

Hydraulic System

15gal

Chain Box - Each Side

2.6gal

Cab

Rops

SAE J1040 MAY94, ISO 3471:1994

Fops

SAE J1043 SEPT87, ISO 3449:1992 Level I

Fops Level Ii

SAE J231 JAN81, ISO 3449:1992 Level II
