Caterpillar 235C Shovel

Caterpillar 235C Shovel Specs side
Caterpillar 235C Shovel Specs side
Caterpillar 235C Shovel Specs back
Caterpillar 235C Shovel Specs back
Caterpillar 235C Shovel Specs extended_1
Caterpillar 235C Shovel Specs extended_1
Caterpillar 235C Shovel Specs extended_2
Caterpillar 235C Shovel Specs extended_2
Caterpillar 235C Shovel Specs extended_3
Caterpillar 235C Shovel Specs extended_3
Units

Dimensions

Backhoe Boom / Stick 1

I

Max Cutting Height

31.34 ft in

J

Max Dump Height

20.71 ft in

L

Max Vertical Wall Dig Depth

15.72 ft in

M

Max Dig Depth

22.87 ft in

Q

Max Cutting Height

31.34 ft in

R

Max Dump Height

20.71 ft in

T

Max Dig Depth

22.87 ft in

Backhoe Boom / Stick 2

I

Max Cutting Height

31.76 ft in

J

Max Dump Height

21.13 ft in

L

Max Vertical Wall Dig Depth

17.03 ft in

M

Max Dig Depth

24.38 ft in

Q

Max Cutting Height

31.76 ft in

R

Max Dump Height

21.13 ft in

T

Max Dig Depth

24.38 ft in

Backhoe Boom / Stick 3

I

Max Cutting Height

32.49 ft in

J

Max Dump Height

21.86 ft in

L

Max Vertical Wall Dig Depth

19.3 ft in

M

Max Dig Depth

26.88 ft in

Q

Max Cutting Height

32.49 ft in

R

Max Dump Height

21.86 ft in

T

Max Dig Depth

26.88 ft in

Dimensions

B

Width Over Tracks

11.32 ft in

E

Ground Clearance

1.74 in

G

Height to Top of Cab

11.16 ft in

Loading Shovel

I

Max Cutting Height

30.09 ft in

J

Max Dump Height

16.51 ft in

Q

Max Cutting Height

30.09 ft in

R

Max Dump Height

16.51 ft in

S

Max Dig Reach

27.33 ft in

Undercarriage

N

Loading Shovel Shoe Width

18 in


Specifications

Engine

Engine Make

2236

Engine Model

3306

Gross Power

250 hp

Displacement

640.8 cu in

Operational

Fuel Capacity

130 gal

Undercarriage

Max Travel Speed

2 mph

Backhoe Shoe Width 1

30 in

Backhoe Shoe Width 2

35.9 in

Backhoe Operating Weight - Shoe 1

92902.9 lb

Backhoe Ground Pressure - Shoe 1

8.8 psi

Backhoe Ground Pressure - Shoe 2

7.5 psi

Loading Shovel Shoe Width

18 in

Loading Shovel Operating Weight

26477.6 lb

Loading Shovel Ground Pressure

15 psi

Backhoe Boom / Stick 1

Backhoe Boom / Stick

Stick 8'0" (2440mm)

Max Dig Depth

22.9 ft in

Max Vertical Wall Dig Depth

15.8 ft in

Max Cutting Height

31.4 ft in

Max Dump Height

20.8 ft in

Max Reach on Ground

35.7 ft in

Backhoe Boom / Stick 2

Backhoe Boom / Stick

Stick 9'6" (2900mm)

Max Dig Depth

24.4 ft in

Max Vertical Wall Dig Depth

17.1 ft in

Max Cutting Height

31.8 ft in

Max Dump Height

21.2 ft in

Max Reach on Ground

37.1 ft in

Backhoe Boom / Stick 3

Backhoe Boom / Stick

Stick 12'0" (3660mm)

Max Dig Depth

26.9 ft in

Max Vertical Wall Dig Depth

19.3 ft in

Max Cutting Height

32.5 ft in

Max Dump Height

21.9 ft in

Max Reach on Ground

39.4 ft in

Loading Shovel

Max Cutting Height

30.1 ft in

Max Dump Height

16.6 ft in

Max Dig Reach

27.4 ft in

Dimensions

Width Over Tracks

11.4 ft in

Height to Top of Cab

11.2 ft in

Length of Tracks

16.5 ft in

Ground Clearance

1.8 in

Upper Structure Ground Clearance

3.7 ft in
