Komatsu H455S Shovel

Komatsu H455S Shovel Specs side
Komatsu H455S Shovel Specs side
Komatsu H455S Shovel Specs back
Komatsu H455S Shovel Specs back
Komatsu H455S Shovel Specs extended_1
Komatsu H455S Shovel Specs extended_1
Komatsu H455S Shovel Specs extended_2
Komatsu H455S Shovel Specs extended_2
Komatsu H455S Shovel Specs extended_3
Komatsu H455S Shovel Specs extended_3
Units

Dimensions

Dimensions

B

Width Over Tracks

23.46 ft in

D

Length of Track on Ground

22.31 ft in

E

Ground Clearance

39.38 in

G

Height to Top of Cab

28.59 ft in

H

Tail Swing Radius

23.5 ft in

Loading Shovel

I

Max Cutting Height

66.77 ft in

J

Max Dump Height

45.94 ft in

M

Max Dig Depth

9.85 ft in

P

Height to Top of Boom - shovel

32.16 ft in

Q

Max Cutting Height

66.77 ft in

R

Max Dump Height

45.94 ft in

S

Max Dig Reach

55.12 ft in

T

Max Dig Depth

9.85 ft in

U

Overall Length - shovel

54.63 ft in

Undercarriage

F

Track Gauge

19.03 ft in

N

Loading Shovel Shoe Width

53.15 in


Specifications

Engine

Number of Cylinders

12

Engine Make

2347

Engine Model

KTTA38C x2

Net Power

2236 hp

Power Measured @

1800 rpm

Displacement

2288 cu in

Aspiration

Turbocharged

Operational

Fuel Capacity

1954.9 gal

Hydraulic System Fluid Capacity

1003.9 gal

Swing Speed

3.6 rpm

Undercarriage

Max Travel Speed

1.4 mph

Track Gauge

19.1 ft in

Loading Shovel Shoe Width

53.2 in

Loading Shovel Operating Weight

1080265.1 lb

Loading Shovel Ground Pressure

32 psi

Loading Shovel

Height to Top of Boom - shovel

32.2 ft in

Overall Length - shovel

54.7 ft in

Max Dig Depth

9.9 ft in

Max Cutting Height

66.8 ft in

Max Dump Height

46 ft in

Max Dig Reach

55.2 ft in

Buckets

Reference Bucket Capacity

36.7 yd3

Dimensions

Width Over Tracks

23.5 ft in

Height to Top of Cab

28.6 ft in

Length of Tracks

29.8 ft in

Length of Track on Ground

22.4 ft in

Ground Clearance

39.4 in

Upper Structure Ground Clearance

10.6 ft in

Tail Swing Radius

23.5 ft in
