Caterpillar 231D Hydraulic Excavator
Units
Dimensions
Boom/Stick Option (Hex) 1
I
Max Cutting Height
33.08ft in
J
Max Loading Height
23.5ft in
K
Max Reach Along Ground
34.91ft in
L
Max Vertical Wall Digging Depth
17.36ft in
M
Max Digging Depth
22.77ft in
Boom/Stick Option (Hex) 1
Stick 9'6" (2900mm)
Boom/Stick Option (Hex) 2
I
Max Cutting Height
33.96ft in
J
Max Loading Height
24.28ft in
K
Max Reach Along Ground
36.75ft in
L
Max Vertical Wall Digging Depth
20.12ft in
M
Max Digging Depth
24.74ft in
Boom/Stick Option (Hex) 2
Stick 11'6" (3500mm)
Dimensions
E
Ground Clearance
1.91ft in
G
Height To Top Of Cab
11.09ft in
B
Width To Outside Of Tracks
11.32ft in
H
Tail Swing Radius
10.13ft in
Removal Counterweight Clearance
4.07ft in
Undercarriage
F
Track Gauge
8.67ft in
N
Shoe Size
32.01in
Max Travel Speed
3.41mph
Drawbar Pull
67442.69lb
Ground Pressure
8.7psi
Specifications
Engine
Engine Make
2236
Engine Model
3208
Gross Power
200hp
Displacement
634.7cu in
Operational
Operating Weight
77602.8lb
Fuel Capacity
105.7gal
Hydraulic System Relief Valve Pressure
4800psi
Hydraulic Pump Flow Capacity
121gal/min
