Caterpillar 226 Skid Steer Loader

Skid Steer Loader
Skid Steer Loader
Skid Steer Loader
Skid Steer Loader
Skid Steer Loader
Skid Steer Loader
Units

Dimensions

Dimensions

A

Length with Bucket

10.61 ft in

B

Width Over Tires

6.01 ft in

C

Height to Top of Cab

6.4 ft in

D

Wheelbase

3.24 ft in

E

Ground Clearance

8 in

F

Length w/o Bucket

8.27 ft in

G

Clearance at Max Lift and Dump

7.12 ft in

H

Reach at Max Lift and Dump

21.5 in


Specifications

Engine

Number of Cylinders

4

Engine Make

2236

Engine Model

3034

Gross Power

58 hp

Net Power

55 hp

Power Measured @

2600 rpm

Displacement

183 cu in

Bore

3.9 in

Stroke

4 in

Engine Model

Cat 3034C

Net Flywheel Power

41 hp

Operational

Operational Weight

5830 lb

Fuel Capacity

15.9 gal

Hydraulic System Fluid Capacity

14.6 gal

Operating Speed

6.9 mph

Max Speed

6.9 mph

Weights

Operating Weight

5645 lb

Loader

Operating Load Rating

1500 lb

Tipping Angle

2710 degrees

Bucket Capacity

0.5 yd3

Hydraulic System

Loader Hydraulic Pressure

3300 psi

Loader Hydraulic Flow

15.1 gal/min

Hydraulic Flow

Standard flow

Hydraulic

Pump Flow Capacity

15.2 gal/min

Dimensions

Length with Bucket

10.7 ft in

Length w/o Bucket

8.3 ft in

Width Over Tires

6.1 ft in

Height to Top of Cab

6.4 ft in

Clearance at Max Lift and Dump

7.2 ft in

Wheelbase

3.3 ft in

Ground Clearance

8 in

Reach at Max Lift and Dump

21.5 in

Turning Radius from Center - inc bucket

79.4 in

Wheel Base

3.3 ft in

Bucket Pin Height - Maximum Lift

9.4 ft in

Height - Top of Cab

6.5 ft in

Length - Without Bucket

99 in

Length - With Bucket on Ground

127 in

Maximum Overall Height

146 in

Bucket Pin Height - Carry Position

9 in

Clearance at Maximum Lift and Dump

85 in

Reach - Maximum Lift/Dump

20 in

Vehicle Width over Tires

60 in

Bumper Overhang - Rear Axle

38 in

Operating Specifications

Rated Operating Capacity with Optional Counterweight

1600 lb

Tipping Load

3000 lb

Breakout Force - Tilt Cylinder

3903 lb

Breakout Force - Lift Cylinder

3136 lb

Rated Operating Capacity

1500 lb

Service Refill Capacities

Cooling System

2.6 gal

Fuel Tank

17 gal

Hydraulic Tank

9.2 gal

Engine Crankcase

2.4 gal

Hydraulic System

14.5 gal

Chain Box - Each Side

1.6 gal

Cab

ROPS

SAE J1040 MAY94 and ISO3471:1994

FOPS

SAEJ/ISO 3449 APR98 Level I and ISO3449:1992 Level I

FOPS Level II

SAEJ/ISO 3449 APR 98 Level II and ISO 3449:1992 Level II (optional)
