Caterpillar 225D LC Hydraulic Excavator

Caterpillar 225D LC Hydraulic Excavator Specs front
Caterpillar 225D LC Hydraulic Excavator Specs front
Caterpillar 225D LC Hydraulic Excavator Specs side
Caterpillar 225D LC Hydraulic Excavator Specs side
Caterpillar 225D LC Hydraulic Excavator Specs extended
Caterpillar 225D LC Hydraulic Excavator Specs extended
Units

Dimensions

Boom/Stick Option (HEX) 1

I

Max Cutting Height

27.79 ft in

J

Max Loading Height

19.13 ft in

K

Max Reach Along Ground

30.29 ft in

L

Max Vertical Wall Digging Depth

10.5 ft in

M

Max Digging Depth

19.53 ft in

Boom/Stick Option (HEX) 2

I

Max Cutting Height

27.5 ft in

J

Max Loading Height

19.07 ft in

K

Max Reach Along Ground

31.4 ft in

L

Max Vertical Wall Digging Depth

10.77 ft in

M

Max Digging Depth

21 ft in

Boom/Stick Option (HEX) 3

I

Max Cutting Height

28.02 ft in

J

Max Loading Height

19.79 ft in

K

Max Reach Along Ground

33.24 ft in

L

Max Vertical Wall Digging Depth

11.59 ft in

M

Max Digging Depth

23 ft in

Dimensions

B

Width to Outside of Tracks

9.81 ft in

E

Ground Clearance

1.24 ft in

G

Height to Top of Cab

10.44 ft in

H

Tail Swing Radius

9.55 ft in

Undercarriage

F

Track Gauge

8.01 ft in

N

Shoe Size

21.66 in


Specifications

Engine

Engine Make

2236

Engine Model

3208

Gross Power

165 hp

Displacement

634.7 cu in

Operational

Operating Weight

58863.5 lb

Fuel Capacity

105.7 gal

Hydraulic System Relief Valve Pressure

4600 psi

Hydraulic Pump Flow Capacity

109.9 gal/min

Undercarriage

Shoe Size

21.7 in

Ground Pressure

8.8 psi

Max Travel Speed

2.3 mph

Drawbar Pull

39791.2 lb

Track Gauge

8.1 ft in

Boom/Stick Option (HEX) 1

Boom/Stick Option (HEX) 1

Stick 6'6" (1980mm)

Max Digging Depth

19.6 ft in

Max Reach Along Ground

30.3 ft in

Max Cutting Height

27.8 ft in

Max Loading Height

19.2 ft in

Max Vertical Wall Digging Depth

10.5 ft in

Boom/Stick Option (HEX) 2

Boom/Stick Option (HEX) 2

Stick 8'0" (2440mm)

Max Digging Depth

21 ft in

Max Reach Along Ground

31.4 ft in

Max Cutting Height

27.5 ft in

Max Loading Height

19.1 ft in

Max Vertical Wall Digging Depth

10.8 ft in

Boom/Stick Option (HEX) 3

Boom/Stick Option (HEX) 3

Stick 10'0" (3050mm)

Max Digging Depth

23 ft in

Max Reach Along Ground

33.3 ft in

Max Cutting Height

28.1 ft in

Max Loading Height

19.8 ft in

Max Vertical Wall Digging Depth

11.6 ft in

Dimensions

Width to Outside of Tracks

9.9 ft in

Height to Top of Cab

10.5 ft in

Ground Clearance

1.3 ft in

Removal Counterweight Clearance

3.5 ft in

Tail Swing Radius

9.6 ft in
