Caterpillar 211B LC Hydraulic Excavator

Caterpillar 211B LC Hydraulic Excavator Specs front
Caterpillar 211B LC Hydraulic Excavator Specs front
Caterpillar 211B LC Hydraulic Excavator Specs side
Caterpillar 211B LC Hydraulic Excavator Specs side
Caterpillar 211B LC Hydraulic Excavator Specs extended
Caterpillar 211B LC Hydraulic Excavator Specs extended
Units

Dimensions

Boom/Stick Option (HEX) 1

I

Max Cutting Height

26.09 ft in

J

Max Loading Height

18.51 ft in

K

Max Reach Along Ground

26.19 ft in

L

Max Vertical Wall Digging Depth

11.95 ft in

M

Max Digging Depth

15.62 ft in

Boom/Stick Option (HEX) 2

I

Max Cutting Height

26.91 ft in

J

Max Loading Height

19.43 ft in

K

Max Reach Along Ground

28.29 ft in

L

Max Vertical Wall Digging Depth

13.46 ft in

M

Max Digging Depth

17.89 ft in

Boom/Stick Option (HEX) 3

I

Max Cutting Height

26.84 ft in

J

Max Loading Height

19.56 ft in

K

Max Reach Along Ground

29.6 ft in

L

Max Vertical Wall Digging Depth

13.59 ft in

M

Max Digging Depth

19.49 ft in

Boom/Stick Option (HEX) 4

I

Max Cutting Height

27.66 ft in

J

Max Loading Height

20.35 ft in

K

Max Reach Along Ground

31.17 ft in

M

Max Digging Depth

21.13 ft in

Boom/Stick Option (HEX) 5

I

Max Cutting Height

28.78 ft in

J

Max Loading Height

21.49 ft in

K

Max Reach Along Ground

33.44 ft in

M

Max Digging Depth

23.43 ft in

Dimensions

B

Width to Outside of Tracks

8.99 ft in

E

Ground Clearance

1.33 ft in

G

Height to Top of Cab

9.77 ft in

H

Tail Swing Radius

7.03 ft in

Undercarriage

F

Track Gauge

7.35 ft in

N

Shoe Size

23.63 in


Specifications

Engine

Engine Make

2236

Engine Model

3114

Gross Power

105 hp

Displacement

268.6 cu in

Operational

Operating Weight

34722.9 lb

Fuel Capacity

71.4 gal

Hydraulic System Fluid Capacity

54.2 gal

Hydraulic System Relief Valve Pressure

4640 psi

Hydraulic Pump Flow Capacity

60.8 gal/min

Undercarriage

Shoe Size

23.7 in

Ground Pressure

5.1 psi

Max Travel Speed

2.8 mph

Drawbar Pull

31473.3 lb

Track Gauge

7.4 ft in

Boom/Stick Option (HEX) 1

Boom/Stick Option (HEX) 1

Stick 5'3" (1600mm)

Max Digging Depth

15.7 ft in

Max Reach Along Ground

26.2 ft in

Max Cutting Height

26.1 ft in

Max Loading Height

18.6 ft in

Max Vertical Wall Digging Depth

12 ft in

Boom/Stick Option (HEX) 2

Boom/Stick Option (HEX) 2

Stick 7'7" (2300mm)

Max Digging Depth

17.9 ft in

Max Reach Along Ground

28.3 ft in

Max Cutting Height

27 ft in

Max Loading Height

19.5 ft in

Max Vertical Wall Digging Depth

13.5 ft in

Boom/Stick Option (HEX) 3

Boom/Stick Option (HEX) 3

Stick 9'2" (2800mm)

Max Digging Depth

19.5 ft in

Max Reach Along Ground

29.6 ft in

Max Cutting Height

26.9 ft in

Max Loading Height

19.6 ft in

Max Vertical Wall Digging Depth

13.6 ft in

Boom/Stick Option (HEX) 4

Boom/Stick Option (HEX) 4

Stick 10'10" (3300mm)

Max Digging Depth

21.2 ft in

Max Reach Along Ground

31.2 ft in

Max Cutting Height

27.7 ft in

Max Loading Height

20.4 ft in

Max Vertical Wall Dig Depth

150.6 ft in

Boom/Stick Option (HEX) 5

Boom/Stick Option (HEX) 5

Stick 13'2" (4000mm)

Max Digging Depth

23.5 ft in

Max Reach Along Ground

33.5 ft in

Max Cutting Height

28.8 ft in

Max Loading Height

21.5 ft in

Max Vertical Wall Dig Depth

17.1 ft in

Dimensions

Width to Outside of Tracks

9 ft in

Height to Top of Cab

9.8 ft in

Ground Clearance

1.4 ft in

Removal Counterweight Clearance

3.6 ft in

Tail Swing Radius

7.1 ft in
