Hitachi ZX160LC Hydraulic Excavator

Hitachi ZX160LC Hydraulic Excavator Specs front
Hitachi ZX160LC Hydraulic Excavator Specs front
Hitachi ZX160LC Hydraulic Excavator Specs side
Hitachi ZX160LC Hydraulic Excavator Specs side
Hitachi ZX160LC Hydraulic Excavator Specs extended
Hitachi ZX160LC Hydraulic Excavator Specs extended
Units

Dimensions

Boom/Stick Option (HEX) 1

A

Shipping Length of Unit

28.32 ft in

C

Shipping Height of Unit

10.24 ft in

I

Max Cutting Height

28.02 ft in

J

Max Loading Height

19.26 ft in

K

Max Reach Along Ground

26.78 ft in

L

Max Vertical Wall Digging Depth

14.01 ft in

M

Max Digging Depth

17.75 ft in

Boom/Stick Option (HEX) 2

A

Shipping Length of Unit

27.99 ft in

C

Shipping Height of Unit

9.45 ft in

I

Max Cutting Height

29.14 ft in

J

Max Loading Height

20.25 ft in

K

Max Reach Along Ground

28.55 ft in

L

Max Vertical Wall Digging Depth

16.93 ft in

M

Max Digging Depth

19.62 ft in

Boom/Stick Option (HEX) 3

A

Shipping Length of Unit

28.09 ft in

C

Shipping Height of Unit

10.21 ft in

I

Max Cutting Height

29.93 ft in

J

Max Loading Height

21 ft in

K

Max Reach Along Ground

30.06 ft in

L

Max Vertical Wall Digging Depth

18.67 ft in

M

Max Digging Depth

21.3 ft in

Dimensions

B

Width to Outside of Tracks

8.17 ft in

D

Length of Track on Ground

10.18 ft in

E

Ground Clearance

1.55 ft in

G

Height to Top of Cab

9.45 ft in

H

Tail Swing Radius

8.01 ft in

Undercarriage

F

Track Gauge

6.53 ft in

N

Shoe Size

19.69 in


Specifications

Engine

Number of Cylinders

4

Engine Make

2353

Engine Model

AA-4BG1TC

Net Power

110 hp

Power Measured @

2150 rpm

Displacement

264.2 cu in

Max Torque

295.1 lb ft

Torque Measured @

1800 rpm

Aspiration

turbocharged, intercooled

Operational

Operating Weight

34392.2 lb

Fuel Capacity

74 gal

Cooling System Fluid Capacity

5.1 gal

Hydraulic System Fluid Capacity

45 gal

Engine Oil Capacity

4.2 gal

Swing Drive Fluid Capacity

1.7 gal

Operating Voltage

24 V

Alternator Supplied Amperage

50 amps

Hydraulic System Relief Valve Pressure

4980 psi

Hydraulic Pump Flow Capacity

73 gal/min

Swing Mechanism

Swing Speed

13.6 rpm

Undercarriage

Number of Shoes per Side

43

Shoe Size

19.7 in

Number of Carrier Rollers per Side

2

Number of Track Rollers per Side

7

Ground Pressure

6.6 psi

Max Travel Speed

3.3 mph

Track Gauge

6.6 ft in

Buckets

Reference Bucket Capacity

0.8 yd3

Minimum Bucket Capacity

0.6 yd3

Maximum Bucket Capacity

1 yd3

Boom/Stick Option (HEX) 1

Boom/Stick Option (HEX) 1

boom 5100mm w/ stick 2010mm

Shipping Height of Unit

10.3 ft in

Shipping Length of Unit

28.4 ft in

Max Digging Depth

17.8 ft in

Max Reach Along Ground

26.8 ft in

Max Cutting Height

28.1 ft in

Max Loading Height

19.3 ft in

Max Vertical Wall Digging Depth

14.1 ft in

Boom/Stick Option (HEX) 2

Boom/Stick Option (HEX) 2

boom 5100mm w/ stick 2580mm

Shipping Height of Unit

9.5 ft in

Shipping Length of Unit

28 ft in

Max Digging Depth

19.7 ft in

Max Reach Along Ground

28.6 ft in

Max Cutting Height

29.2 ft in

Max Loading Height

20.3 ft in

Max Vertical Wall Digging Depth

17 ft in

Boom/Stick Option (HEX) 3

Boom/Stick Option (HEX) 3

boom 5100mm w/ stick 3100mm

Shipping Height of Unit

10.3 ft in

Shipping Length of Unit

28.1 ft in

Max Digging Depth

21.3 ft in

Max Reach Along Ground

30.1 ft in

Max Cutting Height

30 ft in

Max Loading Height

21 ft in

Max Vertical Wall Digging Depth

18.7 ft in

Dimensions

Width to Outside of Tracks

8.2 ft in

Height to Top of Cab

9.5 ft in

Ground Clearance

1.6 ft in

Removal Counterweight Clearance

3.3 ft in

Tail Swing Radius

8.1 ft in

Length of Track on Ground

10.2 ft in
