Case SR150 Skid Steer Loader

Case SR150 Skid Steer Loader Specs front
Case SR150 Skid Steer Loader Specs front
Case SR150 Skid Steer Loader Specs side
Case SR150 Skid Steer Loader Specs side
Case SR150 Skid Steer Loader Specs back
Case SR150 Skid Steer Loader Specs back
Units

Dimensions

Dimensions

A

Length with Bucket

9.95 ft in

B

Width Over Tires

4.99 ft in

C

Height to Top of Cab

6.3 ft in

D

Wheelbase

3.09 ft in

E

Ground Clearance

7 in

F

Length w/o Bucket

8.01 ft in

G

Clearance at Max Lift and Dump

7.39 ft in

H

Reach at Max Lift and Dump

18.5 in


Specifications

Engine

Number of Cylinders

4

Engine Model

ISM N844T/M3

Gross Power

52 hp

Net Power

49 hp

Power Measured @

2900 rpm

Displacement

122 cu in

Max Torque

109 lb ft

Torque Measured @

1750 rpm

Aspiration

Turbocharged

Operational

Operational Weight

5300 lb

Fuel Capacity

16 gal

Engine Oil Fluid Capacity

2 gal

Hydraulic System Fluid Capacity

4 gal

Chain Box Fluid Capacity - each side

1.7 gal

Operating Speed

6.7 mph

Tire Size

10 x 16.5

Operating Voltage

12 V

Alternator Supplied Amperage

120 amps

Loader

Operating Load Rating

1500 lb

Tipping Angle

3030 degrees

Bucket Capacity

0.5 yd3

Bucket Width

60 in

Hydraulic

Pump Type

Gear

Pump Flow Capacity

15.6 gal/min

Relief Valve Pressure

3000 psi

Dimensions

Length with Bucket

10 ft in

Length w/o Bucket

8.1 ft in

Width Over Tires

5 ft in

Height to Top of Cab

6.3 ft in

Clearance at Max Lift and Dump

7.4 ft in

Wheelbase

3.1 ft in

Ground Clearance

7 in

Reach at Max Lift and Dump

18.5 in

Turning Radius from Center - machine rear

56.4 in

Turning Radius from Center - inc bucket

75.6 in
