Case 410 Skid Steer Loader

Skid Steer Loader
Skid Steer Loader
Skid Steer Loader
Skid Steer Loader
Skid Steer Loader
Skid Steer Loader
Units

Dimensions

Dimensions

A

Length with Bucket

10.26ft in

B

Width Over Tires

4.08ft in

C

Height to Top of Cab

6.28ft in

D

Wheelbase

3.43ft in

E

Ground Clearance

8in

F

Length w/o Bucket

8.33ft in

G

Clearance at Max Lift and Dump

7.48ft in

H

Reach at Max Lift and Dump

23.6in


Specifications

Engine

Number of Cylinders

4

Engine Make

2239

Engine Model

422/M2, Tier II certified

Gross Power

51hp

Net Power

49hp

Power Measured @

2900rpm

Displacement

134cu in

Aspiration

Natural

Operational

Operational Weight

5483lb

Fuel Capacity

22gal

Cooling System Fluid Capacity

4.5gal

Engine Oil Fluid Capacity

2.2gal

Hydraulic System Fluid Capacity

13.3gal

Chain Box Fluid Capacity - each side

1.5gal

Operating Speed

6.9mph

Max Speed

6.8mph

Tire Size

10.00 x 16.5

Operating Voltage

12V

Alternator Supplied Amperage

41amps

Loader

Breakout Force

4129

Operating Load Rating

1500lb

Tipping Angle

3000degrees

Bucket Capacity

0.5yd3

Hydraulic

Pump Type

Gear

Pump Flow Capacity

18gal/min

Relief Valve Pressure

3000psi

Dimensions

Length with Bucket

10.3ft in

Length w/o Bucket

8.4ft in

Width Over Tires

4.1ft in

Height to Top of Cab

6.3ft in

Clearance at Max Lift and Dump

7.5ft in

Wheelbase

3.5ft in

Ground Clearance

8in

Reach at Max Lift and Dump

23.6in

Turning Radius from Center - machine rear

57.6in

Turning Radius from Center - inc bucket

73.2in
