Case IH LB 434 ROTTER CUTTER Baler

Baler
Baler
Baler
Baler
Baler
Baler
Units

Specifications

Knotters

Knotters Type

Double knot

Number of knotters

6

Twine ball storage quantity

32

MainDrive

Main drive protection

Shearbolt, overrunning clutch & slip clutch

Sales Literature

Literature Number

CIH07211201

Literature Date

July, 2012

Document Number

HF-5138-12

Document Date

July, 2012

Years of Manufacture

Manufacturing Status

Current

First Entry Date

August,2012

Revision Date

July, 2016

Engine

PTO Speed

1000rpm

Number of remote hydraulic valves

3

Bale Size

Bale height

35.5in

Bale Length - max

108in

Bale Width

47.3in

Baler Pickup

Outer tine-to-tine width

86.7in

Gauge wheels

Two 15x6.00-6 4PR

Pickup working width

92.6in

Tine spacing

2.6in

Number of tine bars

4

Number of tine Rows

4

Number of Tines

68 double (136)

Feeding

Feeder Description

Rotor, 47.2\" (1200 mm), \"W\" tine

Stuffer Description

Fork,6 tines

Weights

Weight Single axle

20062.1lb

Weight tandem axle

21384.9lb

Tires

Tire size Single axle

700/40 R22.5

Tire size Tandem Axle

550/45 R22.5 up to 620/50 R22.5

Plunger

Density Control

3-way monitor control

Plunger speed (strokes/min)

48

Plunger stroke

28in

Wrapping System

Cutter knives

15 or 29 knives, 58 rotor teeth

Dimensions

Length With bale chute folded

296.6in

Baler width

116.1in

Height, single axle

126.9in

Height tandem axle

126.9in

Tractor PTO Power Required

150.2hp

`
