Case CX36B ZTS Mini Excavator

Case CX36B ZTS Mini Excavator Specs front
Case CX36B ZTS Mini Excavator Specs front
Case CX36B ZTS Mini Excavator Specs side
Case CX36B ZTS Mini Excavator Specs side
Case CX36B ZTS Mini Excavator Specs extended
Case CX36B ZTS Mini Excavator Specs extended
Units

Dimensions

Boom/Stick Option (HEX) 1

A

Shipping Length of Unit

15.46 ft in

C

Shipping Height of Unit

8.44 ft in

I

Max Cutting Height

14.34 ft in

J

Max Loading Height

9.98 ft in

K

Max Reach Along Ground

17.2 ft in

L

Max Vertical Wall Digging Depth

7.83 ft in

M

Max Digging Depth

10.11 ft in

Boom/Stick Option (HEX) 2

A

Shipping Length of Unit

15.46 ft in

C

Shipping Height of Unit

8.44 ft in

I

Max Cutting Height

14.74 ft in

J

Max Loading Height

10.34 ft in

K

Max Reach Along Ground

18.05 ft in

L

Max Vertical Wall Digging Depth

8.7 ft in

M

Max Digging Depth

11 ft in

Dimensions

B

Width to Outside of Tracks

5.58 ft in

D

Length of Track on Ground

5.58 ft in

E

Ground Clearance

1.08 ft in

G

Height to Top of Cab

8.42 ft in

H

Tail Swing Radius

2.75 ft in

Undercarriage

F

Track Gauge

4.6 ft in

N

Shoe Size

11.82 in


Specifications

Engine

Number of Cylinders

3

Engine Make

2348

Engine Model

3TNV88-BPYB

Net Power

28.4 hp

Power Measured @

2000 rpm

Displacement

100 cu in

Max Torque

59.1 lb ft

Torque Measured @

1320 rpm

Operational

Operating Weight

8465.8 lb

Fuel Capacity

10 gal

Cooling System Fluid Capacity

1.2 gal

Hydraulic System Fluid Capacity

12.7 gal

Engine Oil Capacity

1.8 gal

Operating Voltage

12 V

Alternator Supplied Amperage

24 amps

Hydraulic System Relief Valve Pressure

3336 psi

Hydraulic Pump Flow Capacity

20.2 gal/min

Swing Mechanism

Swing Speed

9 rpm

Undercarriage

Shoe Size

11.9 in

Number of Carrier Rollers per Side

1

Number of Track Rollers per Side

4

Ground Pressure

4.7 psi

Max Travel Speed

2.8 mph

Drawbar Pull

8655 lb

Track Gauge

4.6 ft in

Buckets

Reference Bucket Capacity

0.1 yd3

Minimum Bucket Capacity

0.1 yd3

Maximum Bucket Capacity

0.2 yd3

Boom/Stick Option (HEX) 1

Boom/Stick Option (HEX) 1

Std. Dipper 1.32M

Shipping Height of Unit

8.5 ft in

Shipping Length of Unit

15.5 ft in

Max Digging Depth

10.2 ft in

Max Reach Along Ground

17.2 ft in

Max Cutting Height

14.4 ft in

Max Loading Height

10 ft in

Max Vertical Wall Digging Depth

7.9 ft in

Boom/Stick Option (HEX) 2

Boom/Stick Option (HEX) 2

Long Dipper 1.59M

Shipping Height of Unit

8.5 ft in

Shipping Length of Unit

15.5 ft in

Max Digging Depth

11 ft in

Max Reach Along Ground

18.1 ft in

Max Cutting Height

14.8 ft in

Max Loading Height

10.4 ft in

Max Vertical Wall Digging Depth

8.7 ft in

Dimensions

Width to Outside of Tracks

5.6 ft in

Height to Top of Cab

8.5 ft in

Ground Clearance

1.1 ft in

Removal Counterweight Clearance

1.9 ft in

Tail Swing Radius

2.8 ft in

Length of Track on Ground

5.6 ft in
