Case 95XT Skid Steer Loader

Skid Steer Loader
Skid Steer Loader
Skid Steer Loader
Skid Steer Loader
Skid Steer Loader
Skid Steer Loader
Units

Dimensions

Dimensions

A

Length with Bucket

11.91ft in

B

Width Over Tires

6.01ft in

C

Height to Top of Cab

6.67ft in

D

Wheelbase

4.2ft in

E

Ground Clearance

9.1in

F

Length w/o Bucket

9.22ft in

G

Clearance at Max Lift and Dump

7.91ft in

H

Reach at Max Lift and Dump

36.82in


Specifications

Engine

Number of Cylinders

4

Engine Make

2239

Engine Model

4T-390

Gross Power

85hp

Net Power

74hp

Power Measured @

2500rpm

Displacement

239cu in

Aspiration

Turbocharged

Operational

Operational Weight

9050lb

Fuel Capacity

20.1gal

Cooling System Fluid Capacity

4.4gal

Engine Oil Fluid Capacity

2.8gal

Hydraulic System Fluid Capacity

17.6gal

Chain Box Fluid Capacity - each side

2.1gal

Max Speed

11.1mph

Tire Size

15.5x16.5

Operating Voltage

12V

Alternator Supplied Amperage

65amps

Loader

Breakout Force

5800

Operating Load Rating

3150lb

Tipping Angle

6300degrees

Bucket Capacity

0.8yd3

Hydraulic

Pump Type

gear pump with integrated constant pressure valve

Pump Flow Capacity

27.6gal/min

Relief Valve Pressure

3002psi

Dimensions

Length with Bucket

12ft in

Length w/o Bucket

9.3ft in

Width Over Tires

6.1ft in

Height to Top of Cab

6.7ft in

Clearance at Max Lift and Dump

8ft in

Wheelbase

4.2ft in

Ground Clearance

9.1in

Reach at Max Lift and Dump

36.9in

Turning Radius from Center - machine rear

65in

Turning Radius from Center - inc bucket

86.3in
