Case 721B Wheel Loader

Wheel Loader
Wheel Loader
Wheel Loader
Wheel Loader
Wheel Loader
Wheel Loader
Units

Dimensions

Dimensions

A

Length with Bucket on Ground

22.81ft in

B

Width Over Tires

7.94ft in

C

Height to Top of Cab

10.67ft in

D

Wheelbase

9.52ft in

E

Ground Clearance

1.38ft in

F

Hinge Pin - Max Height

12.11ft in


Specifications

Engine

Number of Cylinders

6

Max torque ISO TR14396

458.1lb ft

Engine Model

6T-830

Engine Type

4 stroke Direct injection

Net Power

136.6hp

Gross Power

151.6hp

Power Measured @

2100rpm

Torque Measured @

1500rpm

Fuel Type

Diesel

Aspiration

Turbocharged

Bore

4.5in

Stroke

5.4in

Operational

Operating Weight

29762.5lb

Fuel Capacity

53.9gal

Hydraulic System Fluid Capacity

40.5gal

Engine Oil Fluid Capacity

5.6gal

Front Axle/Diff Fluid Capacity

4gal

Rear Axle/Diff Fluid Capacity

2.6gal

Operating Voltage

24V

Alternator Supplied Amperage

65amps

Transmission

Transmission Type

Mechanical

Number of Forward Gears

4

Number of Reverse Gears

4

Max Speed - Forward

22.2mph

Max Speed - Reverse

14.2mph

Hydraulic System

Pump Type

Hydraulic tandem pump

Pump Flow Capacity

57.6gal/min

Raise Time

5.9sec

Dump Time

1.8sec

Lower Time

4.6sec

Bucket

Breakout Force

27629.1lb

Bucket Width

8.3ft in

Bucket Capacity - heaped

2.8yd3

Bucket Capacity - struck

2.4yd3

Dimensions

Length with Bucket on Ground

22.9ft in

Width Over Tires

8ft in

Height to Top of Cab

10.7ft in

Ground Clearance

1.4ft in

Wheelbase

9.6ft in

Hinge Pin - Max Height

12.2ft in

`
