Case 586G Forklift

Case 586G Forklift Specs front
Case 586G Forklift Specs front
Case 586G Forklift Specs side
Case 586G Forklift Specs side
Case 586G Forklift Specs back
Case 586G Forklift Specs back
Units

Dimensions

Dimensions

B

Overall Width

6.93 ft in

C

Overall Height - mast lowered

10.58 ft in

D

Wheelbase

7.06 ft in

E

Ground Clearance

12.01 in

G

Max Fork Height

15 ft in

MAST

H

Mast Tip Forward

45 degrees

I

Mast Tip Rear

15 degrees


Specifications

Engine

Engine Make

2239

Engine Model

4-390

Power

73 hp

Torque

199 lb ft

Power Measured @

2200 rpm

Displacement

239.3 cu in

Torque Measured @

1200 rpm

Operational

Operating Weight

13360.1 lb

Number of Front Wheels

2

Number of Rear Wheels

2

MAST

Load Capacity

6000 lb

Load Center

24 in

Mast Tip Forward

45 degrees

Mast Tip Rear

15 degrees

Lift Speed

105 ft/min

Dimensions

Wheelbase

7.1 ft in

Overall Width

7 ft in

Overall Height - mast lowered

10.6 ft in

Max Fork Height

15 ft in

Turning Radius

11.5 ft in

Ground Clearance

12.1 in
