Case 580SE Loader Backhoe

Case 580SE Loader Backhoe Specs front
Case 580SE Loader Backhoe Specs front
Case 580SE Loader Backhoe Specs side
Case 580SE Loader Backhoe Specs side
Case 580SE Loader Backhoe Specs extended
Case 580SE Loader Backhoe Specs extended
Units

Dimensions

Backhoe

J

Load Height - Std

11.2 ft in

K

Reach From Swivel - Std

17.8 ft in

L

Dig Depth - Std

14.2 ft in

M

Reach at Load Height - Std

6.6 ft in

Dimensions

A

Transport Length

21.76 ft in

B

Transport Width

6.76 ft in

C

Transport Height

18.8 ft in

D

Wheelbase

10.77 ft in

E

Ground Clearance

0.77 ft in

Loader

G

Clearance at Max Dump Height

10 ft in

H

Reach at Max Dump Height

2.26 ft in

I

Dig Depth

5 in


Specifications

Engine

Number of Cylinders

4

Engine Make

Case

Engine Model

4-390

Gross Power

69 hp

Net Power

63 hp

Power Measured @

2200 rpm

Torque Measured @

1200 rpm

Net Max Torque

181 lb ft

Bore

4.1 in

Stroke

4.8 in

Displacement

238 cu in

Operational

Max Weight

10660 lb

Fuel Capacity

26.5 gal

Hydraulic System Fluid Capacity

12.5 gal

Oil System Fluid Capacity

2.8 gal

Cooling System Fluid Capacity

4.8 gal

Tire Size Front - 2wd / 4wd

11L * 16

Rear Tires Size 2wd/4wd

17.5L*24

Operating Voltage

12 V

Alternator Supplied Amperage

42 amps

Backhoe

Dig Depth - Std

14.2 ft in

Dig Depth - Ext

18.3 ft in

Reach From Swivel - Std

17.8 ft in

Reach From Swivel - Ext

21.7 ft in

Bucket Dig Force - Std

11535 lb

Bucket Dig Force - Ext

11586 lb

Load Height - Std

11.2 ft in

Load Height - Ext

14.3 ft in

Reach at Load Height - Std

6.6 ft in

Reach at Load Height - Ext

9 ft in

Transmission

Transmission Type

Full power shuttle and torque converter

Number of Forward Gears

4

Number of Reverse Gears

4

Max Speed - Forward

21.9 mph

Max Speed Reverse

19.6 mph

Loader

Bucket Capacity

1 yd3

Bucket Width

82 in

Bucket Breakout Force

7040 lb

Lift Capacity at Full Height

4390 lb

Clearance at Max Dump Height

10 ft in

Reach at Max Dump Height

2.3 ft in

Dig Depth

5 in

Hydraulic

Pump Type

Front mounted , positive displacement , gear type , taden pump

Pump Flow Capacity

30 gal/min

Relief Valve Pressure

2000 psi

Dimensions

Rear Tread Range

61.9 in

Front Wheel Tread Width

63 in

Transport Length

21.8 ft in

Transport Width

6.8 ft in

Transport Height

18.8 ft in

Height to Top of Suspended Cab

8.8 ft in

Wheelbase

10.8 ft in

Ground Clearance

0.8 ft in
