Case 445CT Series 3 Multi Terrain Loader

Case 445CT Series 3 Multi Terrain Loader Specs front
Case 445CT Series 3 Multi Terrain Loader Specs front
Case 445CT Series 3 Multi Terrain Loader Specs back
Case 445CT Series 3 Multi Terrain Loader Specs back
Case 445CT Series 3 Multi Terrain Loader Specs extended
Case 445CT Series 3 Multi Terrain Loader Specs extended
Units

Dimensions

Dimensions

B

Width Over Tracks

6.93 ft in

C

Height to Top of Cab

6.93 ft in

E

Ground Clearance

11.15 in

G

Clearance at Max Lift and Dump

7.32 ft in

H

Reach at Max Lift and Dump

3.38 ft in

Undercarriage

D

Length of Track on Ground

1638 ft in


Specifications

Engine

Number of Cylinders

4

Engine Make

2239

Engine Model

432T/M3

Gross Power

82 hp

Net Power

77 hp

Power Measured @

2500 rpm

Peak Torque

229 lb ft

Torque Measured @

1400 rpm

Displacement

195 cu in

Aspiration

Turbocharged

Operational

Operating Weight

10200 lb

Fuel Capacity

17.3 gal

Cooling System Fluid Capacity

3.1 gal

Engine Oil Capacity

2.3 gal

Hydraulic System Fluid Capacity

11 gal

Operating Voltage

12 V

Alternator Supplied Amperage

95 amps

Max Speed - low range

5.1 mph

Max Speed - high range

8 mph

Loader

Operating Load

3300 lb

Tipping Angle

6600 degrees

Bucket Capacity

0.8 yd3

Undercarriage

Ground Contact Area

2293 in2

Ground Pressure

4.3 psi

Number of Track Rollers per Side

4

Length of Track on Ground

1638 ft in

Width of Track

17.8 in

Hydraulic

Pump Type

Gear

Pump Flow

23.9 gal/min

Dimensions

Width Over Tracks

7 ft in

Length with Bucket

11.3 ft in

Length with out Bucket

8.7 ft in

Height to Top of Cab

7 ft in

Ground Clearance

11.2 in

Clearance at Max Lift and Dump

7.4 ft in

Reach at Max Lift and Dump

3.4 ft in

Turning Radius from Center - machine rear

55.2 in

Turning Radius from Center - inc bucket

92.2 in
