Case 445 Series III Skid Steer Loader

Case 445 Series III Skid Steer Loader Specs front
Case 445 Series III Skid Steer Loader Specs front
Case 445 Series III Skid Steer Loader Specs side
Case 445 Series III Skid Steer Loader Specs side
Case 445 Series III Skid Steer Loader Specs back
Case 445 Series III Skid Steer Loader Specs back
Units

Dimensions

Dimensions

A

Length with Bucket

10.96 ft in

B

Width Over Tires

6.01 ft in

C

Height to Top of Cab

6.93 ft in

D

Wheelbase

3.75 ft in

E

Ground Clearance

9.3 in

F

Length w/o Bucket

8.7 ft in

G

Clearance at Max Lift and Dump

7.52 ft in

H

Reach at Max Lift and Dump

36.62 in


Specifications

Engine

Number of Cylinders

4

Engine Make

2239

Engine Model

432T/M3 diesel Tier III certified

Gross Power

81.9 hp

Net Power

76.5 hp

Power Measured @

2300 rpm

Displacement

195.3 cu in

Aspiration

Turbocharged

Operational

Operational Weight

8119.7 lb

Fuel Capacity

17.4 gal

Cooling System Fluid Capacity

3.1 gal

Engine Oil Fluid Capacity

2.3 gal

Hydraulic System Fluid Capacity

11 gal

Chain Box Fluid Capacity - each side

2.1 gal

Operating Speed

7 mph

Max Speed

7 mph

Tire Size

12.00 x 16.5 10 ply

Operating Voltage

12 V

Alternator Supplied Amperage

95 amps

Loader

Breakout Force

5000

Operating Load Rating

2500.1 lb

Tipping Angle

5000.1 degrees

Bucket Capacity

0.6 yd3

Hydraulic

Pump Type

Gear

Pump Flow Capacity

23.9 gal/min

Relief Valve Pressure

3050 psi

Dimensions

Length with Bucket

11 ft in

Length w/o Bucket

8.7 ft in

Width Over Tires

6.1 ft in

Height to Top of Cab

7 ft in

Clearance at Max Lift and Dump

7.6 ft in

Wheelbase

3.8 ft in

Ground Clearance

9.3 in

Reach at Max Lift and Dump

36.7 in

Turning Radius from Center - machine rear

53.6 in

Turning Radius from Center - inc bucket

83.5 in
