Case 440CT Multi Terrain Loader
Units
Dimensions
Dimensions
B
Width Over Tracks
5.92ft in
C
Height To Top Of Cab
6.39ft in
E
Ground Clearance
9in
G
Clearance At Max Lift And Dump
8.06ft in
H
Reach At Max Lift And Dump
1.95ft in
Turning Radius From Center - Machine Rear
58in
Length With Bucket
10.6ft in
Turning Radius From Center - Inc Bucket
80.41in
Length With Out Bucket
8.66ft in
Undercarriage
D
Length Of Track On Ground
4.71ft in
I
Track Gauge
4.6ft in
Ground Contact Area
1780in2
Number Of Track Rollers Per Side
3
Width Of Track
15.75in
Ground Pressure
5psi
Specifications
Engine
Number Of Cylinders
4
Engine Make
2239
Engine Model
Family III 445T/M2
Gross Power
89hp
Net Power
82hp
Power Measured @
2300rpm
Peak Torque
263lb ft
Torque Measured @
1400rpm
Displacement
274cu in
Aspiration
turbocharged
Operational
Operating Weight
8915lb
Cooling System Fluid Capacity
4.5gal
Fuel Capacity
22gal
Engine Oil Capacity
3.2gal
Hydraulic System Fluid Capacity
13.2gal
Operating Voltage
12V
Alternator Supplied Amperage
95amps
Max Speed - Low Range
5.1mph
Max Speed - High Range
7.6mph
Loader
Breakout Force
6207lb
Operating Load
3000lb
Tipping Angle
6000degrees
Bucket Capacity
0.7yd3
Hydraulic
Pump Type
gear pump
Pump Flow
21.9gal/min
Relief Valve Pressure
3000psi
