Case 325 Articulated Dump Truck

Articulated Dump Truck
Articulated Dump Truck
Articulated Dump Truck
Articulated Dump Truck
Articulated Dump Truck
Articulated Dump Truck
Units

Dimensions

Dimensions

A

Overall Length

32.25ft in

B

Overall Width

9.17ft in

C

Overall Height

11.94ft in

D

Wheelbase

19.79ft in

E

Ground Clearance

1.71ft in

F

Dump Height

21.17ft in

G

Dump Ground Clearance

2.86ft in

Dump

H

Dump Angle

67degrees


Specifications

Engine

Number of Cylinders

6

Engine Make

2347

Engine Model

6CTAA-8.3

Gross Power

260hp

Net Power

248hp

Power Measured @

2200rpm

Displacement

506cu in

Max Torque

828lb ft

Torque Measured @

1400rpm

Aspiration

Turbocharged and Aftercooled

Operational

Fuel Capacity

86gal

Hydraulic System Fluid Capacity

52.8gal

Engine Oil Capacity

5.8gal

Transmission Fluid Capacity

6.9gal

Operating Voltage

24V

Alternator Supplied Amperage

70amps

Tire Size

tubeless 23.5xR25

Transmission

Transmission Type

Power Shift

Number of Forward Gears

6

Number of Reverse Gears

3

Max Speed

29.6mph

Weights

Front Axle - empty

20172lb

Rear Axle - empty

20944lb

Total Empty

41116lb

Total Loaded

91822lb

Dump

Rated Payload

50706lb

Capacity - Struck

13.9yd3

Capacity - Heaped

17.4yd3

Dump Angle

67degrees

Raise Time

14sec

Lower Time

16sec

Dimensions

Overall Length

32.3ft in

Overall Width

9.2ft in

Overall Height

12ft in

Wheelbase

19.8ft in

Ground Clearance

1.8ft in

Dump Height

21.2ft in

Dump Ground Clearance

2.9ft in
